| 1 | 16958-GJ6-000 | JOINT, FUEL TUBE | 1 шт. | — | |
|
| 2 | 17411-MKJ-D00 | RUBBER, CANISTER MOUNT | 2 шт. | — | |
|
| 3 | 17412-MKJ-E50 | TUBE, JOINT-FIVE WAY | 1 шт. | — | |
|
| 4 | 17413-MKJ-E50 | TUBE | 1 шт. | — | |
|
| 5 | 17414-KZZ-900 | TUBE, FUEL (9X45) | 1 шт. | — | |
|
| 6 | 17414-MKJ-D00 | TUBE (PCSV-CANISTER) | 1 шт. | — | |
|
| 7 | 17415-KZZ-900 | JOINT, TUBE | 1 шт. | — | |
|
| 8 | 17418-MKJ-A00 | TUBE A, CHARGE | 1 шт. | — | |
|
| 9 | 17419-MKJ-A00 | TUBE B, CHARGE | 1 шт. | — | |
|
| 10 | 17420-MKJ-D01 | CANISTER | 1 шт. | — | |
|
| 11 | 17422-MKJ-E50 | TUBE, OPEN AIR | 1 шт. | — | |
|
| 12 | 17423-MKJ-D00 | TUBE, CANISTER DRAIN | 1 шт. | — | |
|
| 13 | 19126-KM1-010 | JOINT, TUBE | 1 шт. | — | |
|
| 14 | 36162-HW5-901 | VALVE, CONTROL SOLENOID (P2) (Honda Code 8954869) | 1 шт. | — | |
|
| 15 | 94050-06080 | NUT, FLANGE (6MM) | 1 шт. | — | |
|
| 16 | 95002-40800-08 | CLAMP, TUBE (D8) | 3 шт. | — | |
|
| 17 | 95002-41000-08 | CLAMP, TUBE (D10) | 0 шт. | — | |
|
| 18 | 90506-425-000 | WASHER, RR. COVER | 1 шт. | — | |
|
