| 1 | 11210-MKJ-E50 | PAN, OIL | 1 шт. | — | |
|
| 2 | 11810-MFA-D00 | GUARD, OIL FILTER | 1 шт. | — | |
|
| 3 | 11815-MFA-D00 | RUBBER, OIL FILTER GUARD | 2 шт. | — | |
|
| 4 | 15100-MEL-000 | PUMP ASSY., OIL | 1 шт. | — | |
|
| 5 | 15134-MEL-000 | SPROCKET, OIL PUMP DRIVEN (25T) | 1 шт. | — | |
|
| 6 | 15141-MEL-003 | CHAIN, OIL PUMP (68L) (BORG WARNER) | 1 шт. | — | |
|
| 7 | 15150-MKJ-E50 | STRAINER, OIL | 1 шт. | — | |
|
| 8 | 15154-MAT-000 | GASKET, OIL STRAINER | 1 шт. | — | |
|
| 9 | 15155-MEL-000 | COLLAR, O-RING | 1 шт. | — | |
|
| 10 | 15220-MFA-D00 | VALVE ASSY., RELIEF | 1 шт. | — | |
|
| 11 | 15410-MFJ-D02 | FILTER, OIL (WAKO FILTER) | 1 шт. | — | |
|
| 12 | 15700-MFA-D01 | COOLER, OIL | 1 шт. | — | |
|
| 13 | 90028-GHB-670 | BOLT, FLANGE (6X22) (S-NSHF) | 2 шт. | — | |
|
| 14 | 90028-GHB-680 | BOLT, FLANGE (6X25) (S-NSHF) | 12 шт. | — | |
|
| 15 | 90028-GHB-650 | BOLT, FLANGE (6X18) | 3 шт. | — | |
|
| 16 | 90019-MB0-000 | BOSS, OIL FILTER (Honda Code 1243435) | 1 шт. | — | |
|
| 17 | 90021-MM5-000 | BOLT-WASHER (6X12) (Honda Code 2551760) | 1 шт. | — | |
|
| 18 | 90402-MFA-D00 | COLLAR, OIL FILTER GUARD | 2 шт. | — | |
|
| 19 | 90403-MFA-D00 | WASHER (6MM) | 2 шт. | — | |
|
| 20 | 91313-MB0-003 | O-RING (14.7X2.2) (ARAI) (Honda Code 1260868) | 2 шт. | — | |
|
| 20 | 91313-MG7-004 | O-RING (14.8X2.2) (Honda Code 3353620) | 2 шт. | — | |
|
| 21 | 91354-MCT-003 | O-RING, OIL COOLER | 1 шт. | — | |
|
| 22 | 92800-12000 | BOLT, DRAIN PLUG (12MM) | 1 шт. | — | |
|
| 23 | 94109-12000 | WASHER, DRAIN PLUG (12MM) | 1 шт. | — | |
|
| 24 | 94301-08140 | PIN, DOWEL (8X14) (Honda Code 0069310) | 2 шт. | — | |
|
| 25 | 95701-06040-00 | BOLT, FLANGE (6X40) BOLT, FLANGE (6X45) | 2 шт. | — | |
|
| 26 | 95701-06050-00 | BOLT, FLANGE (6X50) (Honda Code 2410975) | 1 шт. | — | |
|
| 27 | 15010-MKR-305 | FILTER SET, OIL (Optional). | 1 шт. | — | |
|
