| 1 | 17210-MKR-D10 | ELEMENT, AIR CLEANER | 1 шт. | — | |
|
| 2 | 17215-MKR-A30 | FUNNEL, R. AIR | 1 шт. | — | |
|
| 3 | 17220-MKR-A80 | HOUSING, AIR CLEANER | 1 шт. | — | |
|
| 4 | 17221-MKR-D10 | SEAL A, AIR IN. DUCT | 1 шт. | — | |
|
| 5 | 17225-MKR-A30 | FUNNEL, L. AIR | 1 шт. | — | |
|
| 6 | 17227-MEE-000 | RETAINER, AIR CLEANER ELEMENT | 1 шт. | — | |
|
| 7 | 17230-MKR-D10 | HOUSING, AIR CLEANER (UPPER) | 1 шт. | — | |
|
| 8 | 17239-MJP-G50 | COLLAR, AIR CLEANER MOUNTING | 2 шт. | — | |
|
| 9 | 17239-MKR-D10 | PLATE, PGM-FI UNIT SETTING | 1 шт. | — | |
|
| 10 | 17290-MKR-D10 | MAT, AIR CLEANER | 1 шт. | — | |
|
| 11 | 17291-MKR-D10 | GUARD, AIR CLEANER HEAT | 1 шт. | — | |
|
| 12 | 17366-MKF-D40 | CLIP, TUBE | 1 шт. | — | |
|
| 13 | 17551-MKR-D10 | TUBE, ENGINE BREATHER | 1 шт. | — | |
|
| 14 | 17554-MB0-000 | CLIP, BREATHER TUBE | 1 шт. | — | |
|
| 15 | 17590-MKR-D10 | GUARD, FUEL TANK HEAT | 1 шт. | — | |
|
| 16 | 37880-KWW-C01 | SENSOR ASSY., AIR TEMPERATURE | 1 шт. | — | |
|
| 17 | 46401-TM8-A01 | SENSOR A, MASTER POWER PRESSURE | 1 шт. | — | |
|
| 18 | 83545-KCJ-690 | RUBBER, SIDE COVER | 2 шт. | — | |
|
| 19 | 90101-HW4-680 | SCREW, TAPPING (5X12) (DELTA PT) | 1 шт. | — | |
|
| 20 | 90105-MFJ-D00 | SCREW, TAPPING (4X18) (DELTA PT) | 15 шт. | — | |
|
| 21 | 91508-MGP-D00 | SCREW, PAN (5MM) | 2 шт. | — | |
|
| 22 | 91508-MKF-D40 | SCREW, PAN (5MM) | 4 шт. | — | |
|
| 23 | 93404-06028-07 | BOLT-WASHER (6X28) | 2 шт. | — | |
|
| 24 | 93901-25420 | SCREW, TAPPING (5X20) | 1 шт. | — | |
|
| 25 | 93903-254J0 | SCREW, TAPPING (5X20) (Honda Code 3344546) | 2 шт. | — | |
|
| 26 | 17222-MKR-A30 | MAT A, AIR CLEANER HOUSING (LOWER) | 2 шт. | — | |
|
| 27 | 17223-MKR-A30 | MAT B, AIR CLEANER HOUSING (LOWER) | 1 шт. | — | |
|
