| 1 | 17525-GBC-300 | RUBBER, FUEL TANK | 1 шт. | — | |
|
| 2 | 19010-MKR-D11 | RADIATOR | 1 шт. | — | |
|
| 3 | 19014-KEA-003 | NUT, SETTING (6MM) | 4 шт. | — | |
|
| 4 | 19015-MKR-D11 | SHROUD, R. | 1 шт. | — | |
|
| 5 | 19016-MKR-D11 | SHROUD, L. | 1 шт. | — | |
|
| 6 | 19020-MFA-D01 | FAN, COOLING | 1 шт. | — | |
|
| 7 | 19090-MKR-D61 | MOTOR ASSY., FAN | 1 шт. | — | |
|
| 8 | 19035-KVZ-631 | FILLER, NECK | 1 шт. | — | |
|
| 9 | 19037-GEE-710 | CAP, RADIATOR | 1 шт. | — | |
|
| 10 | 19046-PAA-A00 | LABEL, RADIATOR CAP | 1 шт. | — | |
|
| 11 | 19051-KA3-830 | RUBBER, RADIATOR MOUNTING | 3 шт. | — | |
|
| 12 | 19052-MAC-680 | COLLAR, RADIATOR MOUNTING | 2 шт. | — | |
|
| 13 | 19070-MKR-D10 | JOINT, WATER BYPASS | 1 шт. | — | |
|
| 14 | 19080-MKR-D61 | MOTOR ASSY., FAN | 1 шт. | — | |
|
| 15 | 19090-MKR-D11 | FAN, COOLING | 1 шт. | — | |
|
| 16 | 19101-MKR-D10 | TANK, RADIATOR RESERVE | 1 шт. | — | |
|
| 17 | 19103-ML7-000 | JOINT, TUBE | 1 шт. | — | |
|
| 18 | 19105-MG8-000 | CAP ASSY., RESERVE TANK | 1 шт. | — | |
|
| 19 | 19107-MG8-000 | GASKET, RESERVE TANK | 1 шт. | — | |
|
| 20 | 19120-MKR-D10 | COVER, RADIATOR (UPPER) | 1 шт. | — | |
|
| 21 | 19504-MKR-D10 | HOSE, FILLER NECK | 1 шт. | — | |
|
| 22 | 19511-MKF-D41 | CLAMP, HOSE (D19) | 2 шт. | — | |
|
| 23 | 19514-MKF-D41 | CLAMP, HOSE (D29.8) | 6 шт. | — | |
|
| 24 | 19551-MKR-D10 | HOSE, THERMOSTAT | 1 шт. | — | |
|
| 25 | 19561-MKR-D10 | HOSE, RADIATOR | 1 шт. | — | |
|
| 26 | 19571-MKR-D10 | HOSE, WATER PUMP | 1 шт. | — | |
|
| 27 | 83155-HP6-A00 | SEAL, FUEL TANK | 1 шт. | — | |
|
| 28 | 83551-GE2-000 | GROMMET, AIR CLEANER HOUSING | 1 шт. | — | |
|
| 29 | 90020-GHB-640 | BOLT, FLANGE (6X16) | 1 шт. | — | |
|
| 30 | 90020-GHB-680 | BOLT, FLANGE (6X25) | 1 шт. | — | |
|
| 31 | 90020-GHB-690 | BOLT, FLANGE (6X28) | 1 шт. | — | |
|
| 32 | 90027-GHB-670 | BOLT, FLANGE (6X22) | 3 шт. | — | |
|
| 33 | 90030-GHB-640 | BOLT, FLANGE (6X16) | 1 шт. | — | |
|
| 34 | 90111-KW3-003 | NUT, COWL SETTING (5MM) | 1 шт. | — | |
|
| 35 | 90116-SP0-003 | CLIP, BUMPER SEAL | 2 шт. | — | |
|
| 36 | 90120-GHB-601 | BOLT-WASHER (6X12) | 6 шт. | — | |
|
| 37 | 90127-KF0-770 | COLLAR (6X4) | 1 шт. | — | |
|
| 38 | 90315-MFL-003 | NUT, FLANGE (3MM) | 1 шт. | — | |
|
| 39 | 90315-MK3-003 | NUT, SERRATE (5MM) | 4 шт. | — | |
|
| 40 | 91303-MKR-D11 | O-RING (19X2) | 1 шт. | — | |
|
| 41 | 93893-04008-07 | SCREW-WASHER (4X8) | 3 шт. | — | |
|
| 42 | 94050-06000 | NUT, FLANGE (6MM) | 1 шт. | — | |
|
| 43 | 95002-02100 | CLIP, TUBE (B10) | 2 шт. | — | |
|
| 44 | 95002-02120 | CLIP, TUBE (B12) | 2 шт. | — | |
|
| 45 | 95002-50000 | CLIP, TUBE (C9) | 1 шт. | — | |
|
| 46 | 95005-50003-30M | BULK HOSE, VACUUM (5X3000) (5X180) | 1 шт. | — | |
|
| 47 | 95005-55003-20M | BULK HOSE, VACUUM (5.5X3000) (95005-55001-20M(95005-55001-2 | 1 шт. | — | |
|
| 48 | 95005-750012-0M | BULK TUBE,TB75-1M | 1 шт. | — | |
|
| 49 | 64213-MEJ-J00 | MAT, FR. CENTER COWL | 4 шт. | — | |
|
| 50 | 15653-MKR-D80 | GUARD | 1 шт. | — | |
|
| 51 | 19113-MKR-D80 | STAY, RADIATOR | 1 шт. | — | |
|
| 52 | 39963-MKF-D41 | RUBBER, SENSOR MOUNTING | 2 шт. | — | |
|
| 53 | 90132-MFJ-D00 | BOLT, SPECIAL (6X18) (SUS) | 2 шт. | — | |
|
| 54 | 90301-473-003 | NUT, U (6MM) NUT, FLANGE (6MM) | 2 шт. | — | |
|
| 55 | 90507-MKR-D10 | COLR, HEAT GUARD MT | 2 шт. | — | |
|
