| 1 | 24700-K26-900 | PEDAL ASSY., CHANGE | 1 шт. | — | |
|
| 2 | 24701-K26-305 | PEDAL, GEARSHIFT (COO) | 1 шт. | — | |
|
| 3 | 24701-K26-900 | PEDAL, GEARSHIFT | 1 шт. | — | |
|
| 4 | 24703-KGH-900 | WASHER, CHANGE PEDAL | 2 шт. | — | |
|
| 5 | 24711-K26-900 | ARM, GEARSHIFT | 1 шт. | — | |
|
| 6 | 24720-K26-900 | TIE ROD | 1 шт. | — | |
|
| 7 | 24721-K26-900 | COVER, CHANGE PEDAL | 1 шт. | — | |
|
| 8 | 24721-KW6-960 | COVER, CHANGE PEDAL | 1 шт. | — | |
|
| 9 | 24781-KR3-770 | RUBBER, GEARSHIFT PEDAL | 1 шт. | — | |
|
| 10 | 35350-K26-G01 | SWITCH ASSY., RR. STOP | 1 шт. | — | |
|
| 11 | 35357-K26-900 | SPRING, STOP SWITCH | 1 шт. | — | |
|
| 12 | 46500-K26-G00 | PEDAL, BRAKE | 1 шт. | — | |
|
| 13 | 46513-KPP-900 | SPRING ASSY., BRAKE PEDAL | 1 шт. | — | |
|
| 14 | 90502-155-000 | WASHER, PLAIN (7MM) | 2 шт. | — | |
|
| 15 | 90557-230-000 | WASHER (15.2X25) | 1 шт. | — | |
|
| 16 | 90601-KAF-003 | CLIP, SWITCH COVER | 1 шт. | — | |
|
| 17 | 94201-20120 | PIN, COTTER (2.0X12) | 2 шт. | — | |
|
| 18 | 94511-15000 | CIRCLIP (OUTER) (15MM) | 2 шт. | — | |
|
| 19 | 95701-06020-00 | BOLT, FLANGE (6X20) BOLT, SPECIAL FLANGE (6X22) | 1 шт. | — | |
|
