| 1 | 06410-KWB-600 | DAMPER SET, WHEEL | 1 шт. | — | |
|
| 2 | 41200-K26-G01 | SPROCKET, FINAL DRIVEN (38T) | 1 шт. | — | |
|
| 3 | 42301-K26-G00 | AXLE, RR. WHEEL | 1 шт. | — | |
|
| 4 | 42303-KWB-600 | SLEEVE, RR. WHEEL | 1 шт. | — | |
|
| 5 | 42311-K26-900 | COLLAR, L. RR. WHEEL SIDE | 1 шт. | — | |
|
| 6 | 42312-K26-G00 | COLLAR, R. RR. WHEEL SIDE | 1 шт. | — | |
|
| 7 | 42615-K26-G70 | FLANGE SUB-ASSY., FINAL DRIVEN | 1 шт. | — | |
|
| 8 | 42620-K26-900 | COLLAR, RR. AXLE DISTANCE | 1 шт. | — | |
|
| 9 | 42650-K26-G00ZB | WHEEL SUB-ASSY., RR. *NH303M* (MAT AXIS GRAY METALLIC) | 1 шт. | — | |
|
| 10 | 42653-001-004 | O-RING (40.5X3) (NIPPON DUST KEEPER) | 1 шт. | — | |
|
| 11 | 42711-K26-B03 | TIRE, RR. (130/70-12 56L) (VEE) | 1 шт. | — | |
|
| 12 | 42711-K26-B04 | TIRE, RR. (130/70-12 56L) (IRC) | 1 шт. | — | |
|
| 13 | 42753-KJ9-004 | VALVE, RIM (DUNLOP) | 1 шт. | — | |
|
| 14 | 43251-K26-G01 | DISK, RR. BRAKE | 1 шт. | — | |
|
| 15 | 90105-KGH-900 | BOLT, BRAKE DISK (8X24) | 4 шт. | — | |
|
| 16 | 90128-K26-G00 | BOLT, STUD (10X22) | 4 шт. | — | |
|
| 17 | 90304-KGH-901 | NUT, U (10MM) | 4 шт. | — | |
|
| 18 | 90306-KGH-901 | NUT, U (12MM) (FUJI SEIMITSU) | 1 шт. | — | |
|
| 19 | 90559-K26-G00 | WASHER, RR. AXLE | 2 шт. | — | |
|
| 20 | 90753-051-003 | OIL SEAL (26X37X6) (ARAI) | 1 шт. | — | |
|
| 21 | 91051-K35-V02 | BEARING, RADIAL BALL (6203UU) (NTN) | 1 шт. | — | |
|
| 22 | 91051-K35-V03 | BEARING, RADIAL BALL (6203UU) (FUJIKOSHI) | 1 шт. | — | |
|
| 23 | 91053-K03-H01 | BEARING, RADIAL BALL (6301U L) (NTN) | 2 шт. | — | |
|
| 24 | 91053-K03-H02 | BEARING, RADIAL BALL (6301U L) (FAG) | 2 шт. | — | |
|
| 25 | 91251-KGH-902 | DUST SEAL (27X40X4.5) (NOK) | 1 шт. | — | |
|
