| 1 | 40510-K26-G00 | CASE, DRIVE CHAIN | 1 шт. | — | |
|
| 2 | 40530-K26-G01 | CHAIN, DRIVE (DID420D2-108RB) | 1 шт. | — | |
|
| 3 | 40531-KWV-003 | MASTER LINK (DAIDO) | 1 шт. | — | |
|
| 4 | 40543-K26-G00 | ADJUSTER, CHAIN | 2 шт. | — | |
|
| 5 | 40546-K26-G00 | CAP, SWINGARM END | 2 шт. | — | |
|
| 6 | 42301-K26-900 | AXLE, RR. WHEEL | 1 шт. | — | |
|
| 7 | 52170-K26-900 | SLIDER, CHAIN | 1 шт. | — | |
|
| 8 | 52200-K26-G00 | SWINGARM SUB-ASSY., RR. | 1 шт. | — | |
|
| 9 | 90102-K26-B00 | SCREW, PAN (6X12) | 3 шт. | — | |
|
| 10 | 90122-KWB-600 | WASHER, PIVOT BOLT | 2 шт. | — | |
|
| 11 | 90302-KBP-900 | NUT, SPECIAL (6MM) | 2 шт. | — | |
|
| 12 | 90306-KGH-901 | NUT, U (12MM) (FUJI SEIMITSU) | 1 шт. | — | |
|
| 13 | 90556-MB4-000 | WASHER, FR. SIDE COVER | 2 шт. | — | |
|
| 14 | 93901-25110 | SCREW, TAPPING (5X10) | 2 шт. | — | |
|
| 15 | 94001-06000-0S | NUT, HEX. (6MM) | 2 шт. | — | |
|
| 16 | 94001-06200-0S | NUT, HEX. (6MM) | 2 шт. | — | |
|
