| 1 | 23211-K26-G00 | MAINSHAFT (13T) | 1 шт. | — | |
|
| 2 | 23221-K26-G00 | COUNTERSHAFT | 1 шт. | — | |
|
| 3 | 23415-K26-G00 | BUSH (17MM) | 1 шт. | — | |
|
| 4 | 23421-K26-G00 | GEAR, COUNTER FIRST (37T) | 1 шт. | — | |
|
| 5 | 23422-GB4-770 | BUSH (20X9) | 1 шт. | — | |
|
| 6 | 23422-K26-G00 | BUSH (17MM) | 1 шт. | — | |
|
| 7 | 23427-K26-G00 | BUSH (15MM) | 1 шт. | — | |
|
| 8 | 23431-K26-G00 | GEAR, MAINSHAFT SECOND (18T) | 1 шт. | — | |
|
| 9 | 23441-K26-G00 | GEAR, COUNTERSHAFT SECOND (32T) | 1 шт. | — | |
|
| 10 | 23451-K26-G00 | GEAR, MAINSHAFT THIRD (19T) | 1 шт. | — | |
|
| 11 | 23461-K26-G00 | GEAR, COUNTER THIRD (25T) | 1 шт. | — | |
|
| 12 | 23471-K26-G00 | GEAR, MAINSHAFT FOURTH (29T) | 1 шт. | — | |
|
| 13 | 23481-K26-G00 | GEAR, COUNTER FOURTH (30T) | 1 шт. | — | |
|
| 14 | 23491-K26-G00 | GEAR, MAINSHAFT FIFTH (32T) | 1 шт. | — | |
|
| 15 | 23492-K26-G00 | COLLAR, SPLINE (17X20X11) | 1 шт. | — | |
|
| 16 | 23501-K26-G00 | GEAR, COUNTERSHAFT FIFTH (27T) | 1 шт. | — | |
|
| 17 | 23801-K26-G00 | SPROCKET, DRIVE (15T) | 1 шт. | — | |
|
| 18 | 23802-GN5-910 | PLATE, FIXING | 1 шт. | — | |
|
| 19 | 90405-KYJ-900 | WASHER (17X26X1.0) | 2 шт. | — | |
|
| 20 | 90407-KWW-740 | WASHER (6.2X19X2.3) | 2 шт. | — | |
|
| 21 | 90412-187-000 | WASHER, THRUST (15MM) | 1 шт. | — | |
|
| 22 | 90412-K56-N00 | WASHER, SPECIAL (15MM) | 1 шт. | — | |
|
| 23 | 90452-115-000 | WASHER (17MM) | 1 шт. | — | |
|
| 24 | 90452-KGH-900 | WASHER, SPECIAL (12MM) | 1 шт. | — | |
|
| 25 | 90452-KPH-C00 | WASHER | 1 шт. | — | |
|
| 26 | 90452-KRM-840 | WASHER, SPLINE (17X23X1.6) | 2 шт. | — | |
|
| 27 | 90453-KRM-840 | WASHER, SPLINE (20MM) | 1 шт. | — | |
|
| 28 | 90454-KPS-900 | WASHER B, THRUST (20MM) | 1 шт. | — | |
|
| 29 | 90601-KRM-840 | CIRCLIP (17MM) | 2 шт. | — | |
|
| 30 | 90605-KVS-900 | SET-RING (20MM) | 1 шт. | — | |
|
| 31 | 91003-K1M-T01 | BEARING, RADIAL BALL (15X42X11) | 1 шт. | — | |
|
| 32 | 91013-KSS-901 | BEARING, RADIAL BALL (6001) | 1 шт. | — | |
|
| 33 | 91013-KZV-J01 | BEARING, RADIAL BALL (6001) | 1 шт. | — | |
|
| 34 | 96100-60010-00 | BEARING, RADIAL BALL (6001) | 1 шт. | — | |
|
| 35 | 91015-KSS-901 | BEARING, RADIAL BALL (6203) | 2 шт. | — | |
|
| 36 | 91015-KZV-J01 | BEARING, RADIAL BALL (6203) (NA USE ALT:96100-62030-00) | 0 шт. | — | |
|
| 37 | 91204-KPH-902 | OIL SEAL (17X30X5) (NOK) | 1 шт. | — | |
|
| 38 | 92101-06010-0A | BOLT, HEX. (6X10) | 2 шт. | — | |
|
| 39 | 95701-06014-00 | BOLT, FLANGE (6X14) (Honda Code 2410884) | 2 шт. | — | |
|
