| 1 | 11344-KRH-900 | GROMMET A, RR. COVER | 2 шт. | — | |
|
| 2 | 15772-KRH-G01 | CLIP, TUBE | 5 шт. | — | |
|
| 3 | 15772-GW3-980 | CLIP, BREATHER TUBE | 1 шт. | — | |
|
| 4 | 16180-KRH-901 | T-JOINT | 1 шт. | — | |
|
| 5 | 16905-KRH-900 | CUSHION, FUEL STRAINER | 1 шт. | — | |
|
| 6 | 17260-KRH-900 | FILTER, AIR | 1 шт. | — | |
|
| 7 | 18600-KRH-651 | VALVE ASSY., AIR SUCTION | 1 шт. | — | |
|
| 8 | 18601-KRH-D20 | TUBE, SUCTION | 1 шт. | — | |
|
| 9 | 18602-KRH-A00 | TUBE, REED VALVE | 1 шт. | — | |
|
| 10 | 18604-KRH-A00 | TUBE, AIR SUCTION VALVE CONTROL | 1 шт. | — | |
|
| 11 | 18605-KRH-D20 | TUBE, EXCHANGE | 1 шт. | — | |
|
| 12 | 18610-KRH-D20 | SUB-TANK, RESONATOR | 1 шт. | — | |
|
| 13 | 18656-KRH-900 | TUBE A, INNLET | 1 шт. | — | |
|
| 14 | 18657-KRH-D20 | CASE, WATER INLET | 1 шт. | — | |
|
| 15 | 50543-KRH-A00 | BRACKET, AIR SUCTION VALVE | 1 шт. | — | |
|
| 16 | 83119-KRH-900 | COLLAR, LOCK SETTING | 2 шт. | — | |
|
| 17 | 90101-KRH-900 | BOLT, FLANGE (6MM) | 1 шт. | — | |
|
| 18 | 90110-KRH-900 | BOLT, FLANGE (6MM) | 1 шт. | — | |
|
| 19 | 90678-KRH-900 | CLIP, HOSE | 1 шт. | — | |
|
| 20 | 91405-KRH-900 | CLAMP, TUBE (D17) | 1 шт. | — | |
|
| 21 | 94050-06000 | NUT, FLANGE (6MM) | 2 шт. | — | |
|
| 22 | 95002-02070 | CLIP, TUBE (B7) CLIP, TUBE (B6.5) | 2 шт. | — | |
|
| 23 | 95005-80001-20M | BULK HOSE, VACUUM (8X1000) (8X170) (BULK HOSE: 95005-80008-10M) | 1 шт. | — | |
|
| 24 | 95701-06016-00 | BOLT, FLANGE (6X16) (Honda Code 2410892) | 2 шт. | — | |
|
| 25 | 95701-06020-00 | BOLT, FLANGE (6X20) BOLT, SPECIAL FLANGE (6X22) | 2 шт. | — | |
|
| 26 | 15771-KV6-000 | CLIP, OIL DRAIN TUBE | 1 шт. | — | |
|
