| 1 | 12200-KRH-650 | CYLINDER HEAD | 1 шт. | — | |
|
| 2 | 12204-KRM-305 | GUIDE, VALVE (OVER SIZE) | 2 шт. | — | |
|
| 3 | 12210-KVX-600 | HOLDER, CAMSHAFT | 1 шт. | — | |
|
| 4 | 12212-KRM-840 | PLATE, STOPPER | 1 шт. | — | |
|
| 5 | 12213-KTT-900 | CLIP, VALVE GUIDE | 2 шт. | — | |
|
| 5 | 12213-KRM-840 | CLIP, VALVE GUIDE | 2 шт. | — | |
|
| 6 | 12251-KRM-872 | GASKET, CYLINDER HEAD | 1 шт. | — | |
|
| 7 | 16210-KRH-650 | INSULATOR, CARB | 1 шт. | — | |
|
| 8 | 16214-KRH-651 | GASKET | 1 шт. | — | |
|
| 9 | 31916-KRM-841 | SPARK PLUG (CPR8EA-9) (NGK) | 1 шт. | — | |
|
| 9 | 31926-KRM-841 | SPARK PLUG (CPR9EA-9) (NGK) (NA USE ALT:31916-KRM-841) (Optional). | 0 шт. | — | |
|
| 10 | 32925-958-000 | CLIP, PULSER WIRE | 1 шт. | — | |
|
| 11 | 90002-KRM-840 | BOLT, FLANGE (5X14) | 2 шт. | — | |
|
| 12 | 90035-KRM-840 | BOLT, STUD (8X22) | 2 шт. | — | |
|
| 13 | 90035-KWK-900 | BOLT, STUD (6X19) | 2 шт. | — | |
|
| 14 | 90091-KRM-840 | BOLT, FLANGE SOCKET (6X22) | 2 шт. | — | |
|
| 15 | 90306-KRM-840 | NUT, CYLINDER HEAD | 4 шт. | — | |
|
| 16 | 90404-KPT-A00 | WASHER, PLAIN (12MM) | 4 шт. | — | |
|
| 17 | 90703-KRM-840 | PIN, DOWEL (10X12) | 2 шт. | — | |
|
| 17 | 94301-10120 | PIN, DOWEL (10X12) | 2 шт. | — | |
|
| 18 | 90704-KRM-840 | PIN, DOWEL (6X10) | 2 шт. | — | |
|
| 19 | 91304-KRM-840 | O-RING (33.5X3.0) | 1 шт. | — | |
|
| 20 | 94050-06000 | NUT, FLANGE (6MM) | 2 шт. | — | |
|
| 21 | 95701-06014-00 | BOLT, FLANGE (6X14) (Honda Code 2410884) | 1 шт. | — | |
|
| 22 | 95801-06105-00 | BOLT, FLANGE (6X105) | 2 шт. | — | |
|
