| 1 | 34908-KVJ-911 | BULB, WEDGE BASE (T10) (12V 3.4W) | 1 шт. | — | |
|
| 2 | 34910-GFM-901 | BULB, WEDGE BASE (T10) (12V 1.7W) | 3 шт. | — | |
|
| 3 | 37200-KRH-J01 | SPEEDOMETER ASSY. (MPH/KPH) | 1 шт. | — | |
|
| 4 | 37210-KRH-J01 | SPEEDOMETER (MPH/KPH) | 1 шт. | — | |
|
| 5 | 37213-KRH-901 | KNOB, TRIP | 1 шт. | — | |
|
| 6 | 37220-KRH-601 | CASE ASSY. (UPPER) | 1 шт. | — | |
|
| 7 | 37224-KRH-J01 | SOCKET | 1 шт. | — | |
|
| 8 | 37230-KRH-601 | CASE ASSY. (LOWER) | 1 шт. | — | |
|
| 9 | 37233-KRH-901 | CLAMP | 1 шт. | — | |
|
| 10 | 37243-MG2-000 | RUBBER, SPEEDOMETER MOUNTING | 3 шт. | — | |
|
| 11 | 44830-K79-E01 | CABLE ASSY., SPEEDOMETER | 1 шт. | — | |
|
| 12 | 61311-KRH-J00 | STAY, FR. (UPPER) | 1 шт. | — | |
|
| 13 | 61318-KRH-J00 | BASE, METER | 1 шт. | — | |
|
| 14 | 90158-KCJ-710 | SCREW, PAN (2X6) | 0 шт. | — | |
|
| 15 | 91256-KK3-840 | O-RING (10X1.5) | 1 шт. | — | |
|
| 16 | 93700-05018-0A | SCREW, OVAL (5X18) | 1 шт. | — | |
|
| 17 | 93700-05018-1A | SCREW, OVAL (5X18) | 1 шт. | — | |
|
| 18 | 93893-04010-08 | SCREW-WASHER (4X10) | 2 шт. | — | |
|
| 19 | 93913-24220 | SCREW, TAPPING (4X12) | 1 шт. | — | |
|
| 20 | 93913-24320 | SCREW, TAPPING (4X12) | 3 шт. | — | |
|
| 21 | 93913-24420 | SCREW, TAPPING (4X16) (PO) | 5 шт. | — | |
|
| 22 | 94021-06000-0S | NUT, CAP (6MM) | 3 шт. | — | |
|
| 23 | 94021-06020 | NUT, CAP (6MM) | 3 шт. | — | |
|
| 24 | 94021-06020-0S | NUT, CAP (6MM) | 3 шт. | — | |
|
| 25 | 94022-06020 | NUT, CAP (6MM) | 3 шт. | — | |
|
| 26 | 94103-06000 | WASHER, PLAIN (6MM) | 3 шт. | — | |
|
| 27 | 95701-06012-00 | BOLT, FLANGE (6X12) BOLT, SPECIAL (6X12) | 3 шт. | — | |
|
