| 1 | 23210-KRH-780 | MAINSHAFT (14T) | 1 шт. | — | |
|
| 2 | 23220-KRH-J00 | COUNTERSHAFT | 1 шт. | — | |
|
| 3 | 23421-KRH-780 | GEAR (39T) | 1 шт. | — | |
|
| 4 | 23427-KRM-840 | BUSH (17X20.5X8.0) | 1 шт. | — | |
|
| 5 | 23431-KPN-A00 | GEAR, MAINSHAFT SECOND (16T) | 1 шт. | — | |
|
| 6 | 23432-KRH-780 | BUSH (20MM) | 1 шт. | — | |
|
| 7 | 23432-KVX-600 | BUSH (20MM) | 1 шт. | — | |
|
| 8 | 23441-KPN-A00 | GEAR, COUNTERSHAFT SECOND (30T) | 1 шт. | — | |
|
| 9 | 23451-KPN-A00 | GEAR, MAINSHAFT THIRD (22T) | 1 шт. | — | |
|
| 10 | 23461-KPN-A00 | GEAR, COUNTERSHAFT THIRD (31T) | 1 шт. | — | |
|
| 11 | 23471-KPN-A00 | GEAR, MAINSHAFT FOURTH (25T) | 1 шт. | — | |
|
| 12 | 23481-KPN-A00 | GEAR, COUNTERSHAFT FOURTH (28T) | 1 шт. | — | |
|
| 13 | 23491-KPN-A00 | GEAR, MAINSHAFT FIFTH (32T) | 1 шт. | — | |
|
| 14 | 23501-KPN-A00 | GEAR, COUNTERSHAFT FIFTH (30T) | 1 шт. | — | |
|
| 15 | 23801-KRH-650 | SPROCKET (17T) | 1 шт. | — | |
|
| 16 | 23811-KR3-600 | PLATE A2, FIXING | 1 шт. | — | |
|
| 17 | 90453-KVX-600 | WASHER, SPLINE (20MM) | 2 шт. | — | |
|
| 18 | 90454-KTT-900 | WASHER B, THRUST (20MM) | 3 шт. | — | |
|
| 19 | 90456-KTT-900 | WASHER, THRUST (12MM) | 1 шт. | — | |
|
| 20 | 90458-KVS-900 | WASHER, THRUST (17MM) | 4 шт. | — | |
|
| 21 | 90602-KYY-900 | CIRCLIP (20MM) | 2 шт. | — | |
|
| 22 | 91003-KTT-C01 | BEARING (17X42X12) | 1 шт. | — | |
|
| 23 | 91015-KTT-901 | BEARING (6203) (C3) | 1 шт. | — | |
|
| 24 | 91014-KTT-901 | BEARING (6201U) | 1 шт. | — | |
|
| 25 | 91016-KTT-901 | BEARING (6204) | 1 шт. | — | |
|
| 26 | 91216-KSP-910 | OIL SEAL (20X34X7) | 0 шт. | — | |
|
| 27 | 91216-KSP-911 | OIL SEAL (20X34X7) | 1 шт. | — | |
|
| 28 | 91217-KSP-911 | OIL SEAL (20X34X7) | 1 шт. | — | |
|
| 29 | 93101-06010-0A | BOLT, HEX. (6X10) | 2 шт. | — | |
|
| 30 | 90602-KRM-840 | CIRCLIP (OUTER) (17MM) | 1 шт. | — | |
|
