| 1 | 11103-K24-G00 | BUSH, ENGINE HANGER RUBBER | 1 шт. | — | |
|
| 2 | 11200-KWP-H00 | CRANKCASE, L. | 1 шт. | — | |
|
| 3 | 11203-K24-G00 | BUSH, RR. CUSHION RUBBER (LOWER) | 1 шт. | — | |
|
| 4 | 11204-KWP-D00 | PLATE | 1 шт. | — | |
|
| 5 | 12361-KPL-900 | CAP, TAPT ADJ HOLE | 1 шт. | — | |
|
| 6 | 15421-KPL-900 | SCREEN, OIL FILTER | 1 шт. | — | |
|
| 7 | 15426-KCW-880 | SPRING, OIL FILTER SCREEN | 1 шт. | — | |
|
| 8 | 16236-K74-A00 | CLAMP, OVERFLOW | 1 шт. | — | |
|
| 9 | 80109-K74-N00 | STAY, RR. FENDER | 1 шт. | — | |
|
| 10 | 90008-KPL-900 | BOLT | 1 шт. | — | |
|
| 11 | 90032-KWP-D00 | BOLT B, STUD (7X198) | 2 шт. | — | |
|
| 12 | 90474-KWP-F00 | WASHER, SEALING (8MM) | 2 шт. | — | |
|
| 13 | 91006-KWP-G31 | BEARING (6201) | 1 шт. | — | |
|
| 14 | 91006-KWP-G32 | BEARING (6201) | 1 шт. | — | |
|
| 15 | 91007-KWP-G31 | BEARING (6202) | 1 шт. | — | |
|
| 16 | 91007-KWP-G32 | BEARING (6202) | 1 шт. | — | |
|
| 17 | 91104-KCW-880 | BEARING (6204) | 1 шт. | — | |
|
| 18 | 91202-KWP-D01 | OIL SEAL (20.8X53X6) | 1 шт. | — | |
|
| 19 | 91203-KWP-D01 | OIL SEAL (20X32X6.2) | 1 шт. | — | |
|
| 20 | 91302-001-020 | O-RING (30.8MM) (Honda Code 0001065) | 1 шт. | — | |
|
| 21 | 95701-06016-00 | BOLT, FLANGE (6X16) (Honda Code 2410892) | 2 шт. | — | |
|
| 22 | 95701-08012-00 | BOLT, FLANGE (8X12) | 2 шт. | — | |
|
