| 1 | 11220-KWP-H00 | TUBE, TRANSMISSION BREATHER | 1 шт. | — | |
|
| 2 | 21200-KWP-H00 | CASE, TRANSMISSION | 1 шт. | — | |
|
| 3 | 21395-KWP-902 | GASKET, TRANSMISSION CASE | 1 шт. | — | |
|
| 4 | 23411-KWP-H00 | DRIVESHAFT (19T) | 1 шт. | — | |
|
| 5 | 23421-KVT-G00 | COUNTERSHAFT (13T) | 0 шт. | — | |
|
| 6 | 23421-KWP-H00 | COUNTERSHAFT (13T) | 1 шт. | — | |
|
| 7 | 23421-KWP-H10 | COUNTERSHAFT (13T) | 1 шт. | — | |
|
| 8 | 23422-KWP-F00 | GEAR (51T) | 1 шт. | — | |
|
| 9 | 23422-KWP-H10 | GEAR, COUNTER (51T) | 0 шт. | — | |
|
| 10 | 23430-KWP-H00 | GEAR, FINAL (49T) | 1 шт. | — | |
|
| 11 | 90701-KPL-900 | PIN (8X14) | 2 шт. | — | |
|
| 12 | 91006-KWP-G31 | BEARING (6201) | 1 шт. | — | |
|
| 13 | 91006-KWP-G32 | BEARING (6201) | 1 шт. | — | |
|
| 14 | 91008-KWP-D01 | BEARING, RADIAL BALL (6004UU) (NSK) | 1 шт. | — | |
|
| 15 | 91008-KWP-D02 | BEARING (6004UU) | 1 шт. | — | |
|
| 16 | 91008-KWP-D03 | BEARING, RADIAL BALL (6004UU) (NEI LTD) | 0 шт. | — | |
|
| 17 | 91203-KPL-901 | OIL SEAL (14X20X3.2) | 1 шт. | — | |
|
| 18 | 91204-KWP-D01 | OIL SEAL (14X20X3.2) | 1 шт. | — | |
|
| 19 | 91225-KWP-D01 | OIL SEAL (27X42X7) | 1 шт. | — | |
|
| 20 | 95701-06030-00 | BOLT, FLANGE (6X30) | 4 шт. | — | |
|
| 21 | 95701-06040-00 | BOLT, FLANGE (6X40) BOLT, FLANGE (6X45) | 3 шт. | — | |
|
| 22 | 96100-63010-00 | BEARING, RADIAL BALL (6301) | 1 шт. | — | |
|
