| 1 | 40511-MJE-D00 | CASE, DRIVE CHAIN | 1 шт. | — | |
|
| 2 | 40540-MJE-D01 | CHAIN, DRIVE (DID525V11-120ZB) (STANDARD LINK 118L) | 1 шт. | — | |
|
| 3 | 40540-MJE-D02 | CHAIN, DRIVE (RK525KRW-120LJFZ) (STANDARD LINK 118L) | 1 шт. | — | |
|
| 4 | 40545-MJE-D01 | MASTER LINK (DAIDO) | 1 шт. | — | |
|
| 5 | 40545-MJE-D02 | MASTER LINK (RK) | 1 шт. | — | |
|
| 6 | 42305-MJE-D00 | COLLAR, RR. AXLE | 2 шт. | — | |
|
| 7 | 52101-MKN-D50 | BOLT, SWINGARM PIVOT | 1 шт. | — | |
|
| 8 | 52141-MJE-D00 | COLLAR, CENTER PIVOT DISTANCE | 1 шт. | — | |
|
| 9 | 52142-MJE-D00 | COLLAR, R. PIVOT DISTANCE | 1 шт. | — | |
|
| 10 | 52143-MJE-D00 | COLLAR, L. PIVOT DISTANCE | 1 шт. | — | |
|
| 11 | 52161-KZZ-900 | CAP, RR. SWINGARM | 4 шт. | — | |
|
| 12 | 52170-MJE-D00 | SLIDER, CHAIN | 1 шт. | — | |
|
| 13 | 52171-KR6-000 | WASHER, CHAIN SLIDER | 2 шт. | — | |
|
| 14 | 52200-MKN-D50 | SWINGARM SUB-ASSY., RR. | 1 шт. | — | |
|
| 15 | 90104-KPP-900 | SCREW, PAN (5X12) | 2 шт. | — | |
|
| 16 | 90106-MCF-D00 | BOLT, HEX. (8X50) | 2 шт. | — | |
|
| 17 | 90127-MKN-D50 | SCREW, SPECIAL (6X14) | 2 шт. | — | |
|
| 18 | 90305-MJE-D01 | NUT, U (18MM) | 1 шт. | — | |
|
| 19 | 90309-357-000 | NUT, HEX. (10MM) | 2 шт. | — | |
|
| 20 | 90401-KZ4-890 | WASHER (18X32X2) | 1 шт. | — | |
|
| 21 | 90651-MEW-920 | CIRCLIP (INNER) (37) | 1 шт. | — | |
|
| 22 | 91054-MGS-D31 | BEARING, RADIAL BALL (20X37X9) | 1 шт. | — | |
|
| 23 | 91055-MGS-D31 | BEARING, NEEDLE (30X37X20) | 1 шт. | — | |
|
| 24 | 91071-MR7-003 | BEARING, NEEDLE | 1 шт. | — | |
|
| 25 | 91202-MR7-003 | DUST SEAL (28X37X4) | 1 шт. | — | |
|
| 26 | 91253-KZ3-861 | DUST SEAL (30X37X4) | 1 шт. | — | |
|
