| 1 | 11101-41FA0 | HEAD ASSY, CYLINDER FRONT VL800K6 | 0 шт. | — | |
|
| 2 | 11101-41FB0 | HEAD ASSY, CYLINDER FRONT VL800CK6 MODEL K7/K8; Includes Item(s) 2 | 0 шт. | — | |
|
| 3 | 09206-11004 | PIN (11X14) | 2 шт. | — | |
|
| 4 | 11115-38A71 | GUIDE, VALVE (OS 0.3) OPT | 4 шт. | — | |
|
| 5 | 09103-06101 | BOLT (6X50) | 2 шт. | — | |
|
| 6 | 09103-06102 | BOLT (6X55) | 1 шт. | — | |
|
| 7 | 07130-0680B | BOLT (6X80) | 1 шт. | — | |
|
| 8 | 11123-38A00 | GASKET, CYLINDER HEAD COVER | 1 шт. | — | |
|
| 9 | 11141-41F00 | GASKET, CYLINDER HEAD FRONT | 1 шт. | — | |
|
| 10 | 09103-08370 | BOLT (L:250) | 2 шт. | — | |
|
| 11 | 09103-10133 | BOLT (10X155) | 2 шт. | — | |
|
| 12 | 09103-10134 | BOLT (10X165) | 2 шт. | — | |
|
| 13 | 09160-08130 | WASHER (8.5X24X1.6) | 2 шт. | — | |
|
| 14 | 09160-10039 | WASHER (10.5X22X2.3) | 4 шт. | — | |
|
| 15 | 01550-0625B | BOLT (L:25) | 2 шт. | — | |
|
| 16 | 01550-0630B | BOLT (L:30) | 5 шт. | — | |
|
| 17 | 01550-0640B | BOLT (L:40) | 1 шт. | — | |
|
| 18 | 04211-13189 | KNOCK PIN | 2 шт. | — | |
|
| 19 | 07120-0630B | BOLT (L:30) | 1 шт. | — | |
|
| 20 | 11171-41FA0 | CAP, CYLINDER HEAD COVER FL | 1 шт. | — | |
|
| 21 | 11172-41F00 | CAP, CYLINDER HEAD COVER FR | 0 шт. | — | |
|
| 22 | 11175-38A11 | CAP, INSPECTION INTAKE | 1 шт. | — | |
|
| 23 | 11176-38A11 | CAP, INSPECTION EXHAUST | 1 шт. | — | |
|
| 24 | 11177-38A00 | GASKET, INSPECTION CAP | 2 шт. | — | |
|
| 25 | 11179-10F10 | SPACER, HEAD COVER CAP | 2 шт. | — | |
|
| 26 | 09108-06102 | BOLT, INSPECTION CAP STUD | 1 шт. | — | |
|
| 27 | 09160-06084 | WASHER, HEAD COVER CAP UPPER | 2 шт. | — | |
|
| 28 | 09160-09016 | WASHER, HEAD COVER CAP LOWER | 2 шт. | — | |
|
| 29 | 09241-30004 | PLUG, CYLINDER HEAD | 1 шт. | — | |
|
| 30 | 09320-09016 | CUSHION (9X18X9.5) | 2 шт. | — | |
|
| 31 | 09320-13015 | CUSHION, HEAD COVER BOLT | 2 шт. | — | |
|
| 32 | 01547-0620B | BOLT, INSPECTION CAP | 3 шт. | — | |
|
| 33 | 01547-06507 | BOLT, HEAD COVER CAP | 2 шт. | — | |
|
| 34 | 09159-06093 | NUT, INSPECTION CAP | 0 шт. | — | |
|
| 35 | 09482-00354 | SPARK PLUG, DPR7EA-9 (NGK) | 1 шт. | — | |
|
| 36 | 09482-00355 | SPARK PLUG, X22EPR-U9 (ND) !09482-00354 | 1 шт. | — | |
|
| 37 | 09482-00330 | SPARK PLUG, DPR9EA-9 (NGK) OPT | 1 шт. | — | |
|
| 38 | 09482-00331 | SPARK PLUG, X27EPR-U9 (ND) OPT | 1 шт. | — | |
|
| 39 | 09482-00334 | SPARK PLUG, DPR8EA-9 (NGK) OPT | 1 шт. | — | |
|
| 40 | 09482-00335 | SPARK PLUG, X24EPR-U9 (ND) OPT | 1 шт. | — | |
|
| 41 | 11181-41F00 | UNION, CYLINDER HEAD OUTLET | 1 шт. | — | |
|
| 42 | 11182-38A00 | O RING, OUTLET UNION | 1 шт. | — | |
|
| 43 | 07130-0620B | BOLT | 1 шт. | — | |
|
| 44 | 09301-08007 | BUSH, HEAD COVER BOLT | 2 шт. | — | |
|
| 45 | 17891-41F10 | UNION, CYLINDER HEAD JOINT | 1 шт. | — | |
|
| 46 | 07130-0612B | BOLT, JOINT UNION | 1 шт. | — | |
|
| 47 | 09280-16005 | O RING | 1 шт. | — | |
|
| 48 | 17854-41F01 | HOSE, HEAD JOINT | 1 шт. | — | |
|
| 49 | 09402-28513 | CLAMP, JOINT | 2 шт. | — | |
|
| 50 | 13650-57F00 | SENSOR, WATER TEMP | 1 шт. | — | |
|
| 51 | 09168-12017 | GASKET | 1 шт. | — | |
|
