| 1 | 36610-41FH0 | HARNESS, WIRING MODEL K6 E3,E28 | 0 шт. | — | |
|
| 2 | 36610-41FN0 | HARNESS, WIRING MODEL K6 E33 | 0 шт. | — | |
|
| 3 | 36610-41FL0 | HANRESS, WIRING MODEL K7/K8; Includes Item(s) 2 - 5 | 1 шт. | — | |
|
| 4 | 09481-10501 | FUSE (10A) | 5 шт. | — | |
|
| 5 | 09481-15501 | FUSE (15A) | 1 шт. | — | |
|
| 6 | 36618-33E00 | .COVER,SPEEDOMETER COUPLER | 1 шт. | — | |
|
| 7 | 09407-05410 | CLAMP | 0 шт. | — | |
|
| 8 | 09407-17403 | CLAMP | 4 шт. | — | |
|
| 9 | 09407-14407 | CLAMP (L:145) | 1 шт. | — | |
|
| 10 | 09404-06433 | CLAMP (L:80) | 2 шт. | — | — |
|
| 11 | 09404-06435 | CLAMP (L:135) | 1 шт. | — | |
|
| 12 | 09407-18402 | CLAMP (L:165) | 1 шт. | — | |
|
| 13 | 09407-19401 | CLAMP (L:190) | 1 шт. | — | |
|
| 14 | 37101-41870 | LOCK SET MODEL K6 | 0 шт. | — | |
|
| 15 | 37101-41880 | LOCK SET MODEL K6 E33 | 0 шт. | — | |
|
| 16 | 37102-41870 | LOCK SET MODEL K7/K8 | 1 шт. | — | |
|
| 17 | 37102-41880 | LOCK SET MODEL K7/K8 E33; Includes Item(s) 11 | 1 шт. | — | |
|
| 18 | 37100-41F70 | LOCK ASSY, STEERING | 1 шт. | — | |
|
| 19 | 09139-08016 | SCREW, STEERING LOCK | 2 шт. | — | |
|
| 20 | 37187-41F10 | PROTECTOR, IGNITION SWITCH | 1 шт. | — | |
|
| 21 | 37740-24A00 | SWITCH ASSY, STOP LAMP | 1 шт. | — | |
|
| 22 | 09443-06073 | SPRING, STOP LAMP | 1 шт. | — | |
|
| 23 | 37840-41F00 | SWITCH ASSY, SIDE STAND | 1 шт. | — | |
|
| 24 | 09103-06279 | BOLT | 0 шт. | — | |
|
| 25 | 38500-41F10 | HORN ASSY VL800K6/TK6 | 1 шт. | — | |
|
| 26 | 38500-41F20 | HORN ASSY VL800CK6 | 1 шт. | — | |
|
| 27 | 38500-41F20 | HORN ASSY VL800K7/K8/TK7/TK8 | 1 шт. | — | |
|
| 28 | 01550-0816B | BOLT | 1 шт. | — | |
|
| 29 | 38740-24X50 | RELAY ASSY, FUEL PUMP | 1 шт. | — | |
|
| 30 | 38740-24A00 | RELAY ASSY, HEAD LAMP MODEL K7 | 1 шт. | — | |
|
| 31 | 37146-41F10 | KEY, BLANK OPT | 1 шт. | — | |
|
| 32 | 37146-41FA0 | KEY, BLANK "BOULEVARD" OPT | 1 шт. | — | |
|
| 33 | 36611-16G00 | TAPE, HARNESS (28X50X0.13) 28X50X0.13 | 1 шт. | — | |
|
| 34 | 36920-33C00 | TAPE, WIRING HARNESS 30X50X3.0 | 0 шт. | — | |
|
