| 1 | 06910-MBL-610 | BEARING SET, NEEDLE | 1 шт. | — | |
|
| 2 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 шт. | — | |
|
| 3 | 12361-300-000 | CAP, VALVE ADJ. | 1 шт. | — | |
|
| 4 | 12361-371-980 | CAP, VALVE ADJ. | 1 шт. | — | |
|
| 5 | 41300-MFE-A40 | GEAR ASSY., FINAL | 1 шт. | — | |
|
| 6 | 41305-MB4-770 | RING, STOPPER | 1 шт. | — | |
|
| 7 | 41306-MB0-020 | CAP, BREATHER | 1 шт. | — | |
|
| 8 | 41310-MM8-305 | GEAR SET, FINAL | 1 шт. | — | |
|
| 9 | 41311-MFE-A40 | CASE SET, FINAL | 1 шт. | — | |
|
| 10 | 41320-MBL-611 | COVER SUB-ASSY., FINAL GEAR | 1 шт. | — | |
|
| 11 | 41321-ME5-771 | COVER, GEAR CASE | 1 шт. | — | |
|
| 12 | 41324-MFE-A40 | PLATE, DUST GUARD | 1 шт. | — | |
|
| 13 | 41331-ME9-010 | RETAINER, BEARING | 1 шт. | — | |
|
| 14 | 41332-415-000 | LOCK A, BEARING ADJUSTING (SINGLE TAB) | 1 шт. | — | |
|
| 15 | 41333-415-000 | LOCK B, BEARING ADJUSTING (DOUBLE TABS) | 1 шт. | — | |
|
| 16 | 41410-ME9-770 | JOINT, PINION | 1 шт. | — | |
|
| 17 | 41433-MB0-010 | HOLDER, O-RING | 1 шт. | — | |
|
| 18 | 41436-MB0-310 | PIN, RING GEAR STOPPER | 1 шт. | — | |
|
| 19 | 41437-MB0-310 | SHIM A, STOPPER PIN (0.10) | 1 шт. | — | |
|
| 20 | 41438-MB0-310 | SHIM B, STOPPER PIN (0.15) | 1 шт. | — | |
|
| 21 | 41450-MG8-000 | SHIM A, PINION GEAR (1.82) | 1 шт. | — | |
|
| 22 | 41451-MG8-000 | SHIM B, PINION GEAR (1.88) | 1 шт. | — | |
|
| 23 | 41452-MG8-000 | SHIM C, PINION GEAR (1.94) | 1 шт. | — | |
|
| 24 | 41453-MG8-000 | SHIM D, PINION GEAR (2.00) | 1 шт. | — | |
|
| 25 | 41454-MG8-000 | SHIM E, PINION GEAR (2.06) | 1 шт. | — | |
|
| 26 | 41455-MG8-000 | SHIM F, PINION GEAR (2.12) | 1 шт. | — | |
|
| 27 | 41456-MG8-000 | SHIM G, PINION GEAR (2.18) | 1 шт. | — | |
|
| 28 | 41510-MB0-003 | WASHER, SPECIAL (35X40) | 1 шт. | — | |
|
| 29 | 41530-MB0-000 | SPACER A, RING GEAR (1.82) | 1 шт. | — | |
|
| 30 | 41531-MB0-000 | SPACER B, RING GEAR (1.88) | 1 шт. | — | |
|
| 31 | 41532-MB0-000 | SPACER C, RING GEAR (1.94) | 1 шт. | — | |
|
| 32 | 41533-MB0-000 | SPACER D, RING GEAR (2.00) | 1 шт. | — | |
|
| 33 | 41534-MB0-000 | SPACER E, RING GEAR (2.06) | 1 шт. | — | |
|
| 34 | 41535-MB0-000 | SPACER F, RING GEAR (2.12) | 1 шт. | — | |
|
| 35 | 41536-MB0-000 | SPACER G, RING GEAR (2.18) | 1 шт. | — | |
|
| 36 | 41537-MB0-000 | SPACER H, RING GEAR (2.24) | 1 шт. | — | |
|
| 37 | 41538-MB0-000 | SPACER I, RING GEAR (2.30) | 1 шт. | — | |
|
| 38 | 42625-MAH-000 | COLLAR B, RR. DISTANCE | 1 шт. | — | |
|
| 39 | 90109-ME5-770 | BOLT, SOCKET (8X11) | 1 шт. | — | |
|
| 40 | 90133-MEG-A60 | BOLT, FLANGE (8X27) | 6 шт. | — | |
|
| 41 | 90134-MGE-000 | BOLT, FLANGE (10X35) | 2 шт. | — | |
|
| 42 | 90170-MB0-000 | BOLT, HEX. (6X16) | 1 шт. | — | |
|
| 43 | 90306-MCH-003 | NUT, FLANGE (18MM) | 1 шт. | — | |
|
| 44 | 90381-MT3-000 | NUT, HEX. (16MM) | 1 шт. | — | |
|
| 45 | 90471-580-000 | WASHER (8MM) | 1 шт. | — | |
|
| 46 | 91051-MB0-005 | BEARING, RADIAL BALL (16012C3) | 1 шт. | — | |
|
| 47 | 91051-MG8-005 | BEARING, RADIAL BALL (16012C3) | 1 шт. | — | |
|
| 48 | 91052-MB0-003 | BEARING, RADIAL BALL (57/34C3) | 1 шт. | — | |
|
| 49 | 91052-MG8-005 | BEARING, RADIAL BALL (57/34C3) | 1 шт. | — | |
|
| 50 | 91061-MB0-005 | BEARING, RADIAL BALL (6305) | 1 шт. | — | |
|
| 51 | 91061-MG8-005 | BEARING, RADIAL BALL (6305) (KOYO) | 1 шт. | — | |
|
| 52 | 91261-MB0-003 | OIL SEAL (34X50X7) (ARAI) | 1 шт. | — | |
|
| 53 | 91261-MB0-005 | OIL SEAL (34X50X7) (NOK) | 1 шт. | — | |
|
| 54 | 91262-ME9-003 | OIL SEAL (39X51X7) (ARAI) | 1 шт. | — | |
|
| 55 | 91262-ME9-005 | OIL SEAL (39X51X7) (NOK) | 1 шт. | — | |
|
| 56 | 91265-MB0-000 | OIL SEAL (60X80X8) | 1 шт. | — | |
|
| 57 | 91265-MB0-003 | OIL SEAL (60X80X8) (ARAI) | 1 шт. | — | |
|
| 58 | 91302-001-020 | O-RING (30.8MM) (Honda Code 0001065) | 1 шт. | — | |
|
| 59 | 91356-MB0-000 | O-RING (35.X2X2.4) | 1 шт. | — | |
|
| 60 | 91356-MB0-005 | O-RING (35.2X2.4) (NOK) | 1 шт. | — | |
|
| 61 | 91359-MB0-000 | O-RING (58.5X3.5) | 1 шт. | — | |
|
| 62 | 92101-06012-0A | BOLT, HEX. (6X12) BOLT, FLANGE (6X12) | 1 шт. | — | |
|
| 63 | 92900-10032-0E | BOLT, STUD (10X32) | 4 шт. | — | |
|
| 64 | 94101-06800 | WASHER, PLAIN (6MM) (USED ON TAILLIGHT) | 1 шт. | — | |
|
