| 1 | 40200-MR6-671 | JOINT, YOKE | 1 шт. | — | |
|
| 2 | 40207-MT3-610 | BOOT, JOINT | 1 шт. | — | |
|
| 3 | 40210-MEG-000 | SHAFT ASSY., PROPELLER | 1 шт. | — | |
|
| 4 | 40215-ME9-003 | SPRING, PROPELLER SHAFT | 1 шт. | — | |
|
| 5 | 40221-MB0-000 | RING, STOPPER | 1 шт. | — | |
|
| 6 | 43431-MEG-640 | ARM, RR. BRAKE STOPPER | 1 шт. | — | |
|
| 7 | 43434-ME1-670 | RUBBER, STOPPER ARM | 1 шт. | — | |
|
| 8 | 52100-MFS-000 | SWINGARM ASSY., RR. | 1 шт. | — | |
|
| 9 | 90121-MAM-A60 | BOLT, R. SWINGARM PIVOT (L. SIDE) | 1 шт. | — | |
|
| 10 | 90122-MAM-L40 | BOLT, L. SWINGARM PIVOT (R. SIDE) | 1 шт. | — | |
|
| 11 | 90127-393-000 | BOLT, RR. BRAKE STOPPER | 1 шт. | — | |
|
| 12 | 90129-KFG-000 | BOLT, FLANGE (8X32) | 1 шт. | — | |
|
| 13 | 90133-286-000 | BOLT, RR. BRAKE STOPPER ARM | 1 шт. | — | |
|
| 14 | 90308-MEG-000 | NUT, HEX. (10MM) | 4 шт. | — | |
|
| 15 | 90355-469-000 | NUT, SWINGARM PIVOT LOCK | 1 шт. | — | |
|
| 16 | 90505-425-000 | WASHER (8MM) WASHER A, HANDLE HOLDER | 1 шт. | — | |
|
| 17 | 90524-030-000 | WASHER A, HANDLE HOLDER SETTING | 1 шт. | — | |
|
| 18 | 91066-HA7-672 | BEARING, TAPER ROLLER (17X40X13.25) (KOYO) | 2 шт. | — | |
|
| 19 | 91261-ME9-005 | OIL SEAL (27X43X7) | 1 шт. | — | |
|
| 20 | 94001-08000-0S | NUT, HEX. (8MM) | 2 шт. | — | |
|
| 21 | 94101-08000 | WASHER, PLAIN (8MM) | 1 шт. | — | |
|
| 22 | 94111-10000 | WASHER, SPRING (10MM) | 1 шт. | — | |
|
| 23 | 94201-20180 | PIN, COTTER (2.0X18) PIN, COTTER (2.0X20) | 2 шт. | — | |
|
| 24 | 94201-20200 | PIN, COTTER (2.0X20) PIN, COTTER (2.0X22) | 2 шт. | — | |
|
| 25 | 94201-20220 | PIN, COTTER (2.0X22) PIN, COTTER (2.0X25) | 2 шт. | — | |
|
| 26 | 94201-20250 | PIN, COTTER (2.0X25) PIN, COTTER (2X28) | 2 шт. | — | |
|
| 27 | 94201-20280 | PIN, SPLIT (2.0X28) PIN, COTTER (2.0X32) | 2 шт. | — | |
|
| 28 | 94201-20320 | PIN, COTTER (2.0X32) PIN, COTTER (2.0X35) | 2 шт. | — | |
|
| 29 | 94201-20350 | PIN, COTTER (2.0X35) PIN, COTTER (2.0X22) | 2 шт. | — | |
|
| 30 | 94201-29220 | PIN, COTTER (2.0X22) | 2 шт. | — | |
|
