| 1 | 23220-MGZ-J01 | COUNTERSHAFT | 1 шт. | — | |
|
| 2 | 23421-MKP-D00 | GEAR, COUNTERSHAFT FIRST (46T) | 1 шт. | — | |
|
| 3 | 23441-MKP-D00 | GEAR, COUNTERSHAFT SECOND (40T) | 1 шт. | — | |
|
| 4 | 23442-ML7-000 | COLLAR (28MM) | 1 шт. | — | |
|
| 5 | 23461-MKP-D00 | GEAR, COUNTERSHAFT THIRD (32T) | 1 шт. | — | |
|
| 6 | 23481-MKP-D00 | GEAR, COUNTERSHAFT FOURTH (26T) | 1 шт. | — | |
|
| 7 | 23482-MV9-670 | COLLAR, SPLINE (28X31X9) | 2 шт. | — | |
|
| 8 | 23501-MKP-D00 | GEAR, COUNTERSHAFT FIFTH (23T) | 1 шт. | — | |
|
| 9 | 23521-MKP-D00 | GEAR, COUNTERSHAFT SIXTH (24T) | 1 шт. | — | |
|
| 10 | 23801-MKP-D00 | SPROCKET, DRIVE (15T) | 1 шт. | — | |
|
| 11 | 24261-283-000 | PIN, GEARSHIFT FORK GUIDE | 1 шт. | — | |
|
| 12 | 90037-422-003 | BOLT, SPECIAL (10MM) | 1 шт. | — | |
|
| 13 | 90452-MR7-000 | WASHER, SPLINE (28X34X1.5) | 3 шт. | — | |
|
| 14 | 90454-428-000 | WASHER, THRUST (20X1.00) | 2 шт. | — | |
|
| 15 | 90459-438-000 | WASHER (10.2MM) | 1 шт. | — | |
|
| 16 | 90463-MR7-000 | WASHER, SPLINE (28MM) | 1 шт. | — | |
|
| 17 | 90464-MR7-000 | WASHER, LOCK (28MM) | 1 шт. | — | |
|
| 18 | 90603-MN4-000 | CIRCLIP (28MM) | 3 шт. | — | |
|
| 19 | 91023-MKP-D01 | BEARING, NEEDLE (20X34X16.8) (NTN) | 1 шт. | — | |
|
| 20 | 91026-MGZ-J00 | BEARING, NEEDLE (20X24X11) | 1 шт. | — | |
|
| 21 | 91026-MKP-DN1 | BEARING (20X24X11) | 1 шт. | — | |
|
| 22 | 91207-KT8-003 | OIL SEAL (34X62X8) | 1 шт. | — | |
|
| 23 | 94560-62200 | RING, SNAP (62MM) | 1 шт. | — | |
|
