| 1 | 64450-K26-G00 | COVER, FUEL TANK | 1 шт. | — | |
|
| 2 | 64470-K26-G00 | COVER, R. FUEL TANK | 1 шт. | — | |
|
| 3 | 64570-K26-G00 | COVER, L. FUEL TANK | 1 шт. | — | |
|
| 4 | 83450-K26-GE0ZB | SET ILLUS*NHB61P* | 1 шт. | — | |
|
| 5 | 83460-K26-GE0ZB | SET ILLUS *NHB61P* | 1 шт. | — | |
|
| 6 | 83495-K26-G00ZC | GARNISH, BOLT *NHA40M* (MAT KRYPTON SILVER METALLIC) | 6 шт. | — | |
|
| 7 | 83544-K26-GD0ZB | SHROUD SET B, R. *NH436M* (WL) (MAT GUNPOWDER BLACK METALLIC) | 1 шт. | — | |
|
| 8 | 83554-K26-GD0ZB | SHROUD SET B, L. *NH436M* (WL) (MAT GUNPOWDER BLACK METALLIC) | 1 шт. | — | |
|
| 9 | 83560-K26-G50 | SHROUD, R. (INNER) | 1 шт. | — | |
|
| 10 | 83570-K26-G00 | SHROUD, L. (INNER) | 1 шт. | — | |
|
| 11 | 90102-K26-G00 | SCREW, PAN (5X14) | 6 шт. | — | |
|
| 12 | 90104-KPH-900 | SCREW, SPECIAL (5MM) | 2 шт. | — | |
|
| 13 | 90106-K26-900 | SCREW, PAN (6X12) | 2 шт. | — | |
|
| 14 | 90115-KWW-620 | SCREW, VISOR SPECIAL SETTING | 8 шт. | — | |
|
| 15 | 90116-K0A-E11 | RIVET, PUSH (6MM) | 10 шт. | — | |
|
| 16 | 90302-KWW-A00 | NUT, SPRING (4MM) | 4 шт. | — | |
|
| 17 | 90651-K14-A31 | CLIP, SLIDE | 10 шт. | — | |
|
| 18 | 90666-K59-A11 | CLIP, SNAP FITTING (PO) | 4 шт. | — | |
|
| 19 | 90677-KAN-961 | NUT, CLIP (5MM) | 8 шт. | — | |
|
| 20 | 90852-KPP-T00 | PLUG, HOLE | 1 шт. | — | |
|
| 21 | 93903-24380 | SCREW, TAPPING (4X12) | 4 шт. | — | |
|
