| 1 | 33741-MKC-A05 | REFLECTOR, R. FR. REFLEX | 1 шт. | — | |
|
| 2 | 33742-MKC-A05 | REFLECTOR, L. FR. REFLEX | 1 шт. | — | |
|
| 3 | 51114-MKC-A00 | GROMMET, FR. FORK | 2 шт. | — | |
|
| 4 | 51117-MKC-A00 | CAP, STEM PIPE | 1 шт. | — | |
|
| 5 | 51119-MKC-A00ZC | FORK SUB-ASSY., FR. (TYPE3) | 1 шт. | — | |
|
| 6 | 51200-MKC-A00ZC | HOLDER ASSY., FR. FORK (TYPE3) | 1 шт. | — | |
|
| 7 | 51365-MKC-A00 | COLLAR, L. PIVOT DISTANCE | 1 шт. | — | |
|
| 8 | 51366-MKC-A00 | COLLAR B, R. PIVOT DISTANCE | 1 шт. | — | |
|
| 9 | 53157-MKC-A01 | END, R. TIE ROD (RIGHT HAND THREAD) | 2 шт. | — | |
|
| 10 | 53158-MKC-A01 | END, L. TIE ROD (LEFT HAND THREAD) | 2 шт. | — | |
|
| 11 | 53159-MKC-A00 | COVER, TIE ROD | 4 шт. | — | |
|
| 12 | 53214-MKC-A01 | DUST SEAL (UPPER) | 1 шт. | — | |
|
| 13 | 53215-MKC-A01 | DUST SEAL (LOWER) | 1 шт. | — | |
|
| 14 | 53220-MKC-A00 | THREAD, STEERING HEAD TOP | 1 шт. | — | |
|
| 15 | 53233-MKC-A00 | SEAL, FR. FORK | 1 шт. | — | |
|
| 16 | 53240-MKC-A00 | ARM, STEERING | 1 шт. | — | |
|
| 17 | 53242-MKC-A00 | CAP, NUT | 2 шт. | — | |
|
| 18 | 53521-MKC-A00 | TIE ROD, STEERING | 2 шт. | — | |
|
| 19 | 90134-MEL-000 | BOLT (8X45) | 4 шт. | — | |
|
| 20 | 90174-MKC-A00 | BOLT, HEAD PIPE PIVOT (UPPER) | 1 шт. | — | |
|
| 21 | 90175-MKC-A00 | BOLT, HEAD PIPE PIVOT (LOWER) | 1 шт. | — | |
|
| 22 | 90176-MKC-A00 | BOLT, FLANGE (12X78) | 1 шт. | — | |
|
| 23 | 90301-MG8-000 | NUT, FLANGE (5MM) (FUSE RASHI) | 2 шт. | — | |
|
| 24 | 90304-GE8-003 | NUT, U (10MM) NUT, SELF-LOCK (10MM) | 2 шт. | — | |
|
| 25 | 90305-MCB-610 | NUT, SPECIAL U (16MM) | 2 шт. | — | |
|
| 26 | 90306-KV6-911 | NUT, U FLANGE (12MM) | 1 шт. | — | |
|
| 27 | 90311-MKC-A00 | NUT A, HEX. (10MM) | 2 шт. | — | |
|
| 28 | 90315-MKC-A00 | NUT B, HEX. (10MM) (LH) | 2 шт. | — | |
|
| 29 | 90502-MKC-A00 | WASHER, LOCK | 1 шт. | — | |
|
| 30 | 90504-MKC-A00 | WASHER (10X20X1.0) | 4 шт. | — | |
|
| 31 | 91061-MKC-A01 | BEARING, HEAD PIPE (UPPER) | 1 шт. | — | |
|
| 32 | 91062-MKC-A01 | BEARING, HEAD PIPE (LOWER) | 1 шт. | — | |
|
| 33 | 91253-HL1-A01 | OIL SEAL (22X30X5) | 1 шт. | — | |
|
| 34 | 91283-ML7-003 | DUST SEAL (22X29X4) (ARAI) | 1 шт. | — | |
|
