| 1 | 16712-MN5-000 | RUBBER, FUEL PUMP STOPPER | 2 шт. | — | |
|
| 2 | 50280-MKC-A00 | STAY, SHELTER | 1 шт. | — | |
|
| 3 | 77200-MKC-L01ZB | SEAT, DOUBLE HEATED (TYPE1) | 1 шт. | — | |
|
| 4 | 77205-286-000 | RUBBER B, SEAT SETTING | 2 шт. | — | |
|
| 5 | 77206-426-000 | RUBBER, SEAT SETTING | 2 шт. | — | |
|
| 6 | 77206-MKC-A00 | STAY, R. FR. SEAT | 1 шт. | — | |
|
| 7 | 77207-MKC-A00 | STAY, L. FR. SEAT | 1 шт. | — | |
|
| 8 | 77500-MKC-L01ZB | HEATED SEAT, BACK (TYPE1) | 1 шт. | — | |
|
| 9 | 81250-MKC-A00 | PLATE, HELMET HOLDER | 1 шт. | — | |
|
| 10 | 81810-MKC-L80ZA | CUSHION, R. ARMREST (TYPE1) | 1 шт. | — | |
|
| 11 | 81820-MKC-L80ZA | CUSHION, L. ARMREST (TYPE1) | 1 шт. | — | |
|
| 12 | 81830-MKC-A30 | NUT, ARMREST PLATE | 2 шт. | — | |
|
| 13 | 84110-MKC-AE0ZA | GRIP ASSY., L. PASSENGER *NHA86M* (MAT BALLISTIC BLACK) | 1 шт. | — | |
|
| 14 | 84150-MKC-AE0ZA | GRIP, R. PASSENGER *NHA86M* (MAT BALLISTIC BLACK) | 1 шт. | — | |
|
| 15 | 84160-MKC-AE0ZA | BUTTON, HELMET HOLDER *NHA86M* (MAT BALLISTIC BLACK) | 1 шт. | — | |
|
| 16 | 84163-MKC-A00 | SPRING, BUTTON RETURN | 1 шт. | — | |
|
| 17 | 84166-MKC-A00 | PLATE B, HELMET HOLDER | 1 шт. | — | |
|
| 18 | 84167-MKC-L01 | CABLE, HELMET HOLDER | 1 шт. | — | |
|
| 19 | 90106-MAV-000 | SCREW, PAN (6X12) | 4 шт. | — | |
|
| 20 | 90107-KTW-900 | BOLT, SPECIAL (M6) | 2 шт. | — | |
|
| 21 | 90124-MEB-770 | BOLT, FLANGE (8X32) | 4 шт. | — | |
|
| 22 | 90450-KG8-000 | COLLAR (8MM) | 6 шт. | — | |
|
| 23 | 90677-KAN-961 | NUT, CLIP (5MM) | 4 шт. | — | |
|
| 24 | 93901-24380 | SCREW, TAPPING (4X12) | 1 шт. | — | |
|
| 25 | 93903-24310 | SCREW, TAPPING (4X12) | 1 шт. | — | |
|
| 26 | 93903-25380 | SCREW, TAPPING (5X16) | 6 шт. | — | |
|
| 27 | 94050-05070 | NUT, FLANGE (5MM) | 2 шт. | — | |
|
| 28 | 94101-08800 | WASHER, PLAIN (8MM) | 2 шт. | — | |
|
| 29 | 94103-04800 | WASHER, PLAIN (4MM) | 1 шт. | — | |
|
| 30 | 94103-08800 | WASHER, PLAIN (8MM) | 4 шт. | — | |
|
| 31 | 96700-08022-18 | BOLT, SOCKET (8X22) | 2 шт. | — | |
|
