| 1 | 51400-MLC-D01 | FORK ASSY., FR. R | 1 шт. | — | |
|
| 2 | 51401-MLC-D01 | SPRING, FR. R FORK | 2 шт. | — | |
|
| 3 | 51403-MLC-D01 | COLLAR, SPRING | 2 шт. | — | |
|
| 4 | 51406-MW4-003 | STOPPER, SPRING SEAT | 2 шт. | — | |
|
| 5 | 51410-MLC-D01 | TUBE (OUTER) | 2 шт. | — | |
|
| 6 | 51412-KA4-711 | RING, BACK-UP | 2 шт. | — | |
|
| 7 | 51414-MFN-D01 | BUSH, GUIDE | 2 шт. | — | |
|
| 8 | 51415-MFN-D01 | BUSH, SLIDER | 2 шт. | — | |
|
| 9 | 51425-MLC-D01 | PIPE COMP, R SLIDE | 1 шт. | — | |
|
| 10 | 51430-MLC-D01 | DAMPER COMP, FR. | 1 шт. | — | |
|
| 11 | 51447-KA4-711 | RING, OIL SEAL STOPPER (SHOWA) | 2 шт. | — | |
|
| 12 | 51450-MLC-D01 | BOLT COMP, FR. FORK | 2 шт. | — | |
|
| 13 | 51451-MAJ-G41 | NUT, HEX. (10MM) | 2 шт. | — | |
|
| 14 | 51490-MLC-D01 | SEAL SET, FR. FORK | 2 шт. | — | |
|
| 15 | 51500-MLC-D01 | FORK ASSY., FR. L | 1 шт. | — | |
|
| 16 | 51525-MLC-D01 | PIPE COMP, L SLIDE | 1 шт. | — | |
|
| 17 | 51530-MLC-D01 | DAMPER COMP, FR. | 1 шт. | — | |
|
| 18 | 90105-MLC-D00 | BOLT (8X45) | 4 шт. | — | |
|
| 19 | 90116-KV3-701 | BOLT, SOCKET (8MM) (SHOWA) | 2 шт. | — | |
|
| 20 | 90544-283-000 | WASHER, SPECIAL (8MM) (SHOWA) | 2 шт. | — | |
|
| 21 | 91254-MLC-D01 | DUST SEAL | 2 шт. | — | |
|
| 22 | 91356-KZ3-003 | O-RING (44.7X2.4) | 2 шт. | — | |
|
