| 1 | 11103-KVB-901 | BUSH, ENGINE HANGER RUBBER (HOKUSHIN) | 1 шт. | — | |
|
| 2 | 11200-K2S-N00 | CRANKCASE COMP, L. | 1 шт. | — | |
|
| 3 | 11203-KVB-901 | BUSH, RR. CUSHION RUBBER (LOWER) (HOKUSHIN) | 1 шт. | — | |
|
| 4 | 11205-GBC-300 | BUSH, MAIN STAND | 1 шт. | — | |
|
| 5 | 11208-K40-F00 | PLATE, L. CRANKSHAFT BEARING SETTING | 1 шт. | — | |
|
| 6 | 11343-KVG-900 | TUBE, DRAIN | 1 шт. | — | |
|
| 7 | 11410-K1N-V00 | COVER ASSY., ENGINE TOP | 1 шт. | — | |
|
| 8 | 11412-K1N-V00 | SEAL, ENGINE TOP COVER | 1 шт. | — | |
|
| 9 | 15201-K0R-V00 | JET, PISTON | 1 шт. | — | |
|
| 10 | 15411-K0R-V00 | COVER, OIL FILTER | 1 шт. | — | |
|
| 11 | 15421-K0R-V00 | SCREEN, OIL FILTER | 1 шт. | — | |
|
| 12 | 15426-K0R-V00 | SPRING, OIL FILTER SCREEN | 1 шт. | — | |
|
| 13 | 32112-K1N-V00 | PROTECTOR, SPEED SENSOR | 1 шт. | — | |
|
| 14 | 37700-K0L-D11 | SENSOR ASSY., SPEED | 1 шт. | — | |
|
| 15 | 83551-376-000 | GROMMET, SIDE COVER | 1 шт. | — | |
|
| 16 | 90001-KWR-000 | BOLT, SOCKET (6X18) | 3 шт. | — | |
|
| 17 | 90003-883-000 | BOLT, FLANGE (6X16) | 2 шт. | — | |
|
| 18 | 95701-06016-08 | BOLT, FLANGE (6X16) | 2 шт. | — | |
|
| 19 | 90003-K0J-N00 | BOLT, SPECIAL (6X12) | 1 шт. | — | |
|
| 20 | 90032-K0R-V00 | BOLT B, STUD (8X213.2) | 2 шт. | — | |
|
| 21 | 90131-883-000 | BOLT, DRAIN PLUG (12X15) | 1 шт. | — | |
|
| 22 | 90131-896-650 | BOLT, DRAIN PLUG (12X15) | 1 шт. | — | |
|
| 23 | 90495-MN5-000 | WASHER, SEALING (8MM) | 1 шт. | — | |
|
| 24 | 91002-K1N-V01 | BEARING, RADIAL BALL (35X72X15) | 1 шт. | — | |
|
| 25 | 91003-KZR-601 | BEARING, RADIAL BALL (6204) (NTN) | 1 шт. | — | |
|
| 26 | 91005-K2S-N01 | BRG (6301) | 1 шт. | — | |
|
| 27 | 91016-K1Z-J11 | BEARING, RADIAL BALL (6004) (NTN) | 1 шт. | — | |
|
| 28 | 91202-K97-T01 | OIL, SEAL (26X45X6) | 1 шт. | — | |
|
| 29 | 91203-K50-T01 | OIL SEAL (20X32X6) | 1 шт. | — | |
|
| 30 | 91303-K0R-V01 | O-RING (31.2X2.4) | 1 шт. | — | |
|
| 31 | 91304-K0L-D01 | O-RING (11.4X2.1) | 1 шт. | — | |
|
| 32 | 91305-K0J-N00 | O-RING (3.8X1.4) | 1 шт. | — | |
|
| 33 | 94109-12000 | WASHER, DRAIN PLUG (12MM) | 1 шт. | — | |
|
| 34 | 95002-80000 | CLIP, TUBE (C12) | 1 шт. | — | |
|
| 35 | 95701-06016-00 | BOLT, FLANGE (6X16) (Honda Code 2410892) | 1 шт. | — | |
|
| 36 | 95701-08016-00 | BOLT, FLANGE (8X16) | 1 шт. | — | |
|
