| 1 | 19037-K12-941 | CAP, RADIATOR | 1 шт. | — | |
|
| 2 | 19049-K27-V51 | O-RING A | 1 шт. | — | |
|
| 3 | 19051-K27-V51 | O-RING B | 1 шт. | — | |
|
| 4 | 19052-K27-V51 | O-RING C | 1 шт. | — | |
|
| 5 | 19100-K0W-JA0 | RADIATOR ASSY. | 1 шт. | — | |
|
| 6 | 19105-K2S-N00 | BASE COMP, RADIATOR | 1 шт. | — | |
|
| 7 | 19109-GET-003 | SEAL, DRAIN | 1 шт. | — | |
|
| 8 | 19150-K1N-V00 | COVER, RADIATOR | 1 шт. | — | |
|
| 9 | 19416-K01-900 | COLLAR | 3 шт. | — | |
|
| 10 | 19416-KEY-900 | COLLAR | 4 шт. | — | |
|
| 11 | 19501-K0R-V00 | HOSE A, WATER | 1 шт. | — | |
|
| 12 | 19502-K40-A00 | HOSE B, WATER | 1 шт. | — | |
|
| 13 | 19510-K1F-V00 | FAN, COOLING | 1 шт. | — | |
|
| 14 | 84601-HA7-670 | NUT, FENDER SETTING | 3 шт. | — | |
|
| 15 | 90103-GET-003 | BOLT, DRAIN | 1 шт. | — | |
|
| 16 | 90602-K27-V01 | CLAMP, HOSE (D20) | 2 шт. | — | |
|
| 17 | 90701-KWN-901 | CLAMP, WATER HOSE (24MM) | 2 шт. | — | |
|
| 18 | 93401-06030-08 | BOLT-WASHER (6X30) | 4 шт. | — | |
|
| 19 | 95701-06016-00 | BOLT, FLANGE (6X16) (Honda Code 2410892) | 3 шт. | — | |
|
| 20 | 96001-06025-07 | BOLT, FLANGE (6X25) BOLT, FLANGE (6X22) | 3 шт. | — | |
|
