| 1 | 40510-KAE-870 | CASE, DRIVE CHAIN | 1 шт. | — | |
|
| 2 | 40510-KR6-000 | CASE, DRIVE CHAIN | 1 шт. | — | |
|
| 3 | 40535-KV3-405 | MASTER LINK SET (DAIDO) | 1 шт. | — | |
|
| 4 | 40535-KV3-406 | MASTER LINK SET (RK EXCEL) | 1 шт. | — | |
|
| 5 | 40540-KV3-405 | CHAIN, DRIVE (DID520V8-120ZB) (DAIDO) (STANDARD LINK 120L) (STANDARD LINK 110L) | 1 шт. | — | |
|
| 6 | 40540-KV3-406 | CHAIN, DRIVE (RK EXCEL) (RK520MOZ6-120LJ-FZ) (STANDARD LINK 120L) (STANDARD LINK 110L) | 1 шт. | — | |
|
| 7 | 42307-MY6-670 | WASHER, R. RR. SWINGARM | 1 шт. | — | |
|
| 8 | 42308-MY6-670 | WASHER, L. RR. SWINGARM | 1 шт. | — | |
|
| 9 | 43468-KAE-000 | GUIDE, RR. BRAKE HOSE | 2 шт. | — | |
|
| 10 | 50911-MN1-670 | SLIPPER, CHAIN | 1 шт. | — | |
|
| 11 | 50912-MN1-670 | STAY, CHAIN SLIPPER | 1 шт. | — | |
|
| 12 | 52109-430-300 | BUSH, PIVOT THRUST | 2 шт. | — | |
|
| 13 | 52141-MN1-670 | COLLAR, SWINGARM | 1 шт. | — | |
|
| 14 | 52144-356-005 | CAP, SWINGARM DUST SEAL (NOK) | 2 шт. | — | |
|
| 15 | 52146-MN1-671 | GUIDE, CHAIN | 1 шт. | — | |
|
| 16 | 52147-MN1-670 | SLIDER, CHAIN GUIDE | 1 шт. | — | |
|
| 17 | 52156-KV6-000 | PIN, CHAIN ADJUSTER | 2 шт. | — | |
|
| 18 | 52170-MN1-681 | SLIDER, CHAIN | 1 шт. | — | |
|
| 19 | 52171-KR6-000 | WASHER, CHAIN SLIDER | 2 шт. | — | |
|
| 20 | 52180-MY6-670 | GUARD, CHAIN | 1 шт. | — | |
|
| 21 | 52200-MY6-305 | SWINGARM SET | 1 шт. | — | |
|
| 22 | 90103-MY6-670 | BOLT, FLANGE (6X16) | 2 шт. | — | |
|
| 23 | 90104-ML7-920 | SCREW, PAN (5X10) | 2 шт. | — | |
|
| 24 | 90113-MY6-670 | BOLT, FLANGE (6X10) | 1 шт. | — | |
|
| 25 | 90115-KV3-700 | SCREW, PAN (5X8) | 2 шт. | — | |
|
| 26 | 90121-KK3-830 | BOLT, SWINGARM PIVOT | 1 шт. | — | |
|
| 27 | 90301-473-003 | NUT, U (6MM) NUT, FLANGE (6MM) | 2 шт. | — | |
|
| 28 | 90305-GE8-003 | NUT, U (14MM) | 1 шт. | — | |
|
| 29 | 90501-MN1-680 | COLLAR, CHAIN SLIPPER | 1 шт. | — | |
|
| 30 | 90513-405-000 | WASHER (6X9) | 2 шт. | — | |
|
| 31 | 90513-428-900 | WASHER (6X9) | 2 шт. | — | |
|
| 32 | 91070-GC4-601 | BEARING, NEEDLE (20X26X20) (TOYO) BEARING, SWINGARM PIVOT | 2 шт. | — | |
|
| 33 | 93600-05010-0A | SCREW, FLAT (5X10) | 4 шт. | — | |
|
| 34 | 93600-06045-0A | SCREW, FLAT (6X45) | 2 шт. | — | |
|
| 35 | 96201-80000 | FITTING, GREASE (B.76S) | 1 шт. | — | |
|
| 36 | 96300-06012-07 | BOLT, FLANGE (6X12) | 2 шт. | — | |
|
| 37 | 96400-06032-00 | BOLT, FLANGE (6X32) | 1 шт. | — | |
|
