| 1 | 4SH-82100-22-00 | Battery Assy (Yuasa Ytx20l-Bs) | 1 шт. | — | |
|
| 2 | 120-82131-00-00 | Band, Battery | 1 шт. | — | |
|
| 3 | 4NK-82115-00-00 | Wire, Plus Lead | 1 шт. | — | |
|
| 4 | 1D6-82116-00-00 | Wire, Minus Lead | 1 шт. | — | |
|
| 5 | 90464-18246-00 | Clamp | 1 шт. | — | |
|
| 6 | 4XY-82501-20-00 | Main Switch Steering Lock | 1 шт. | — | |
|
| 7 | 5PX-82511-09-00 | Blank Key AP | 1 шт. | — | |
|
| 8 | 4BH-82511-09-00 | Blank Key AP | 1 шт. | — | |
|
| 9 | 90109-08195-00 | Bolt | 2 шт. | — | |
|
| 10 | 4XY-8291G-00-00 | Cover, Switch | 1 шт. | — | |
|
| 11 | 90149-06264-00 | Screw | 2 шт. | — | |
|
| 12 | 90480-01558-00 | Grommet | 1 шт. | — | |
|
| 13 | 4XY-82545-00-00 | Grommet | 1 шт. | — | |
|
| 14 | 4XY-82530-00-00 | Stop Switch Assy | 1 шт. | — | |
|
| 15 | 4XY-82539-00-00 | Stay, Stop Switch | 1 шт. | — | |
|
| 16 | 4XY-82590-10-00 | Wire Harness Assy | 1 шт. | — | |
|
| 17 | 42X-82151-00-00 | . .Fuse (10A-Bl) | 8 шт. | — | |
|
| 18 | 36Y-82151-00-00 | . .Fuse (15A-Bl) | 3 шт. | — | |
|
| 19 | 1NL-82151-00-00 | . .Fuse (5A-Bl) | 3 шт. | — | |
|
| 20 | 3WP-81980-00-00 | . .Diode Assy | 1 шт. | — | |
|
| 21 | 90464-16061-00 | Clamp | 2 шт. | — | |
|
| 22 | 98907-06012-00 | Screw, Bind | 2 шт. | — | |
|
| 23 | 4XY-81953-00-00 | Stay, Relay | 1 шт. | — | |
|
| 24 | 97707-50016-00 | Screw, Truss Head Tapping | 1 шт. | — | |
|
| 25 | 90464-25217-00 | Clamp | 2 шт. | — | |
|
| 26 | 90464-07209-00 | Clamp | 1 шт. | — | |
|
| 27 | 90464-15195-00 | Clamp | 1 шт. | — | |
|
| 28 | 90464-20191-00 | Clamp | 3 шт. | — | |
|
| 29 | 90464-20213-00 | Clamp | 1 шт. | — | |
|
| 30 | 90464-12036-00 | Clamp | 1 шт. | — | |
|
| 31 | 1UA-82591-00-00 | Band | 1 шт. | — | |
|
| 32 | 90464-35132-00 | Clamp | 3 шт. | — | |
|
| 33 | 90464-12089-00 | Clamp | 4 шт. | — | |
|
| 34 | 90464-13073-00 | Clamp | 1 шт. | — | |
|
| 35 | 90464-10112-00 | Clamp | 1 шт. | — | |
|
| 36 | 90464-12036-00 | Clamp | 1 шт. | — | |
|
| 37 | 90464-16061-00 | Clamp | 4 шт. | — | |
|
| 38 | 90464-12036-00 | Clamp | 1 шт. | — | |
|
| 39 | 1UA-82591-00-00 | Band | 2 шт. | — | |
|
| 40 | 90464-13077-00 | Clamp | 3 шт. | — | |
|
| 41 | 4BH-81940-02-00 | Starter Relay Assy (Rc19-005) | 1 шт. | — | |
|
| 42 | 1AE-82151-00-00 | . Fuse (30A-Bl) | 2 шт. | — | |
|
| 43 | 95027-06008-00 | Bolt, Flange | 2 шт. | — | |
|
| 44 | 4XY-81960-00-00 | Rectifier & Regulator Assy | 1 шт. | — | |
|
| 45 | 95807-06020-00 | Bolt, Flange | 2 шт. | — | |
|
| 46 | 5EA-81950-00-00 | Relay Assy (5Ea-00) FOR SIDESTAND | 1 шт. | — | |
|
| 47 | 1UY-81950-92-00 | Relay Assy (1Uy-92) | 1 шт. | — | |
|
| 48 | 5FU-82560-20-00 | Thermo Switch Assy | 1 шт. | — | |
|
| 49 | 3LD-82566-50-00 | Switch, Side Stand | 1 шт. | — | |
|
| 50 | 90157-05079-00 | Screw, Pan Head | 2 шт. | — | |
|
| 51 | 90464-10190-00 | Clamp | 1 шт. | — | |
|
| 52 | 1UA-82591-00-00 | Band | 2 шт. | — | |
|
| 53 | 4XY-83980-10-00 | Front Stop Switch Assy | 1 шт. | — | |
|
| 54 | 98907-04014-00 | Screw, Bind | 1 шт. | — | |
|
| 55 | 4XY-82917-00-00 | Switch | 1 шт. | — | |
|
| 56 | 98907-04025-00 | Screw, Bind | 1 шт. | — | |
|
| 57 | 4XY-8254B-00-00 | Terminal Comp | 1 шт. | — | |
|
| 58 | 4XY-82114-00-00 | Nut | 1 шт. | — | |
|
| 59 | 4BH-82576-01-00 | Sensor, Lean Angle | 1 шт. | — | |
|
| 60 | 90464-16061-00 | Clamp | 1 шт. | — | |
|
| 61 | 4XY-8232Y-00-00 | Wire, Earth Lead | 1 шт. | — | |
|
| 62 | 95807-06010-00 | Bolt, Flange | 2 шт. | — | |
|
| 63 | 4XY-82519-01-00 | Wire, Earth Lead | 1 шт. | — | |
|
| 64 | 95807-06010-00 | Bolt, Flange | 2 шт. | — | |
|
| 65 | 4XY-81950-00-00 | Relay Assy (4Xy-00) | 1 шт. | — | |
|
