| 1 | 4XY-27410-10-00 | Front Footrest Assy (Left) | 1 шт. | — | |
|
| 2 | 4NK-27451-10-00 | . .Footrest | 1 шт. | — | |
|
| 3 | 4XY-27413-01-00 | . .Cover, Footrest | 1 шт. | — | |
|
| 4 | 3D8-27427-00-00 | . .Shaft | 1 шт. | — | |
|
| 5 | 4NK-27426-00-00 | . .Spring, Return | 1 шт. | — | |
|
| 6 | 99001-06600-00 | . Circlip | 1 шт. | — | |
|
| 7 | 4NK-27496-00-00 | . .Mole 1 | 1 шт. | — | |
|
| 8 | 90157-05095-00 | . .Screw, Pan Head | 2 шт. | — | |
|
| 9 | 92907-05200-00 | . Washer | 2 шт. | — | |
|
| 10 | 90110-10161-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 11 | 4XY-27420-10-00 | Front Footrest Assy (Right) | 1 шт. | — | |
|
| 12 | 4NK-27461-10-00 | . .Footrest | 1 шт. | — | |
|
| 13 | 4XY-27423-01-00 | . .Cover, Footrest | 1 шт. | — | |
|
| 14 | 3D8-27427-00-00 | . .Shaft | 1 шт. | — | |
|
| 15 | 4NK-27426-00-00 | . .Spring, Return | 1 шт. | — | |
|
| 16 | 99001-06600-00 | . Circlip | 1 шт. | — | |
|
| 17 | 4NK-27497-00-00 | . .Mole 2 | 1 шт. | — | |
|
| 18 | 90157-05095-00 | . .Screw, Pan Head | 2 шт. | — | |
|
| 19 | 92907-05200-00 | . Washer | 2 шт. | — | |
|
| 20 | 90110-10161-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 21 | 4XY-27430-00-00 | Rear Footrest Assy 1 | 1 шт. | — | |
|
| 22 | 4YE-27433-00-00 | . .Cover, Rear Footrest | 0 шт. | — | |
|
| 23 | 4YE-27437-01-00 | . .Washer, Special | 1 шт. | — | |
|
| 24 | 4YE-27427-01-00 | . .Shaft | 1 шт. | — | |
|
| 25 | 99001-06600-00 | . Circlip | 1 шт. | — | |
|
| 26 | 90501-13720-00 | . .Spring, Compression | 1 шт. | — | |
|
| 27 | 93501-04011-00 | . Ball | 1 шт. | — | |
|
| 28 | 92017-08040-00 | Bolt, Button Head | 2 шт. | — | |
|
| 29 | 4XY-27440-00-00 | Rear Footrest Assy 2 | 1 шт. | — | |
|
| 30 | 4YE-27433-00-00 | . .Cover, Rear Footrest | 0 шт. | — | |
|
| 31 | 4YE-27437-01-00 | . .Washer, Special | 1 шт. | — | |
|
| 32 | 4YE-27427-01-00 | . .Shaft | 1 шт. | — | |
|
| 33 | 99001-06600-00 | . Circlip | 1 шт. | — | |
|
| 34 | 90501-13720-00 | . .Spring, Compression | 1 шт. | — | |
|
| 35 | 93501-04011-00 | . Ball | 1 шт. | — | |
|
| 36 | 92017-08040-00 | Bolt, Button Head | 2 шт. | — | |
|
| 37 | 4NK-27443-00-00 | Bracket 3 | 1 шт. | — | |
|
| 38 | 91317-08014-00 | Bolt | 2 шт. | — | |
|
| 39 | 4XY-27311-00-00 | Stand, Side | 1 шт. | — | |
|
| 40 | 90387-1215U-00 | Collar | 1 шт. | — | |
|
| 41 | 90105-12460-00 | Bolt, Flange | 1 шт. | — | |
|
| 42 | 90185-12134-00 | Nut, Self-Locking | 1 шт. | — | |
|
| 43 | 90506-35474-00 | Spring, Tension | 1 шт. | — | |
|
