| 1 | 4XY-W2846-00-P4 | Travel Trunk Lower Set SMM | 1 шт. | — | |
|
| 2 | 2C9-2840H-60-00 | . .Graphic Set, Travel Trunk | 1 шт. | — | |
|
| 3 | 4XY-28445-00-00 | . .Emblem | 1 шт. | — | |
|
| 4 | 2C9-W2847-00-P0 | Travel Trunk Upper Set SMM | 1 шт. | — | |
|
| 5 | 4XY-28428-00-00 | . .Seal 1 | 1 шт. | — | |
|
| 6 | 4XY-2845E-01-00 | Hinge 2 | 1 шт. | — | |
|
| 7 | 4XY-2849E-01-00 | Hinge 4 | 1 шт. | — | |
|
| 8 | 2C9-2846K-00-P1 | Cover, Hinge 1 SMM | 1 шт. | — | |
|
| 9 | 2C9-2846L-00-P1 | Cover, Hinge 2 SMM | 1 шт. | — | |
|
| 10 | 97707-40010-00 | .Screw, Tapping | 4 шт. | — | |
|
| 11 | 4XY-28487-00-00 | Plate 2 | 1 шт. | — | |
|
| 12 | 4XY-28497-00-00 | Plate 3 | 1 шт. | — | |
|
| 13 | 4XY-28485-00-00 | Plate, Rubber 3 | 2 шт. | — | |
|
| 14 | 92017-05014-00 | Bolt, Button Head | 6 шт. | — | |
|
| 15 | 4XY-28486-01-00 | Bracket 5 | 1 шт. | — | |
|
| 16 | 4XY-28496-01-00 | Bracket 6 | 1 шт. | — | |
|
| 17 | 4XY-28484-00-00 | Plate, Rubber 2 | 2 шт. | — | |
|
| 18 | 92017-05020-00 | Bolt, Button Head | 6 шт. | — | |
|
| 19 | 4XY-28483-00-00 | Plate, Rubber 1 | 2 шт. | — | |
|
| 20 | 4XY-2848M-00-00 | Seat 4 | 2 шт. | — | |
|
| 21 | 4XY-2848L-00-00 | Seat 3 | 1 шт. | — | |
|
| 22 | 90269-05039-00 | Rivet | 8 шт. | — | |
|
| 23 | 4XY-28488-00-00 | Hook | 2 шт. | — | |
|
| 24 | 92017-05008-00 | Bolt, Button Head | 4 шт. | — | |
|
| 25 | 90201-05725-00 | Washer, Plate | 4 шт. | — | |
|
| 26 | 4XY-2845L-01-00 | Stopper, Open | 1 шт. | — | |
|
| 27 | 4XY-2842L-00-00 | Pin, Stopper | 1 шт. | — | |
|
| 28 | 99001-04600-00 | Circlip | 1 шт. | — | |
|
| 29 | 98707-04010-00 | .Screw, Flat Head | 2 шт. | — | |
|
| 30 | 4XY-2843F-00-00 | Cover Assy | 1 шт. | — | |
|
| 31 | 92017-05010-00 | Bolt, Button Head | 1 шт. | — | |
|
| 32 | 2C9-8816E-00-P1 | Base, Remote Control SMM | 1 шт. | — | |
|
| 33 | 4XY-88169-01-00 | Remote Control 1 | 1 шт. | — | |
|
| 34 | 4XY-88137-00-00 | . .Knob | 1 шт. | — | |
|
| 35 | 4XY-88157-00-00 | . .Button 1 | 1 шт. | — | |
|
| 36 | 97707-40010-00 | .Screw, Tapping | 1 шт. | — | |
|
| 37 | 90183-05024-00 | Nut, Spring | 1 шт. | — | |
|
| 38 | 98707-05014-00 | Screw, Flat Head | 1 шт. | — | |
|
| 39 | 4XY-28426-00-00 | Bracket 1 | 1 шт. | — | |
|
| 40 | 4XY-2848J-00-00 | Plate, Rubber 8 | 2 шт. | — | |
|
| 41 | 4XY-2841R-00-00 | Plate, Bottom | 2 шт. | — | |
|
| 42 | 92017-06030-00 | Bolt, Button Head | 4 шт. | — | |
|
| 43 | 4XY-2847J-00-00 | Plate, Rubber 7 | 2 шт. | — | |
|
| 44 | 92017-05014-00 | Bolt, Button Head | 4 шт. | — | |
|
| 45 | 90179-05523-00 | Nut | 4 шт. | — | |
|
| 46 | 98707-05020-00 | Screw, Flat Head | 4 шт. | — | |
|
| 47 | 2C9-2841L-00-P1 | Body SMM | 1 шт. | — | |
|
| 48 | 4XY-28436-00-00 | Bracket 2 | 1 шт. | — | |
|
| 49 | 2C9-88165-00-P1 | Grille, Speaker 1 SMM | 0 шт. | — | |
|
| 50 | 2C9-88175-00-P1 | Grille, Speaker 2 SMM | 1 шт. | — | |
|
| 51 | 4XY-88161-00-00 | Speaker 1 | 2 шт. | — | |
|
| 52 | 95707-05500-00 | Nut, Flange | 8 шт. | — | |
|
| 53 | 4XY-88176-00-00 | Cord | 1 шт. | — | |
|
| 54 | 90183-05024-00 | Nut, Spring | 1 шт. | — | |
|
| 55 | 98707-05016-00 | Screw, Flat Head | 1 шт. | — | |
|
| 56 | 4XY-2846H-01-00 | Plate,4 | 1 шт. | — | |
|
| 57 | 4XY-28417-01-00 | Plate | 1 шт. | — | |
|
| 58 | 90152-05009-00 | Screw, Countersunk | 2 шт. | — | |
|
| 59 | 90154-05064-00 | Screw, Binding | 2 шт. | — | |
|
| 60 | 90183-05024-00 | Nut, Spring | 2 шт. | — | |
|
| 61 | 98507-05012-00 | .Screw, Pan Head | 2 шт. | — | |
|
| 62 | 92907-05600-00 | Washer, Plate | 2 шт. | — | |
|
| 63 | 2C9-2844J-00-P1 | Cover 4 SMM | 1 шт. | — | |
|
| 64 | 90183-05024-00 | Nut, Spring | 4 шт. | — | |
|
| 65 | 92014-05014-00 | Bolt, Button Head | 4 шт. | — | |
|
| 66 | 90202-05088-00 | Washer, Plate | 4 шт. | — | |
|
| 67 | 90338-24260-00 | Plug | 1 шт. | — | |
|
| 68 | 1JK-21268-00-00 | Seal | 2 шт. | — | |
|
| 69 | 1D6-2153E-00-00 | Emblem, Yamaha | 1 шт. | — | |
|
| 70 | 4XY-2848N-00-00 | Seat 5 | 1 шт. | — | |
|
| 71 | 4XY-2848P-00-00 | Seat 6 | 1 шт. | — | |
|
| 72 | 4XY-2848R-00-00 | Seat 7 | 1 шт. | — | |
|
| 73 | 4XY-W2841-00-00 | Lock Assy 1 | 1 шт. | — | |
|
| 74 | 97007-05020-00 | Bolt | 4 шт. | — | |
|
| 75 | 92907-05600-00 | Washer, Plate | 4 шт. | — | |
|
| 76 | 90183-05024-00 | Nut, Spring | 4 шт. | — | |
|
| 77 | 4KN-2475M-00-00 | Seal | 1 шт. | — | |
|
| 78 | 4XY-28493-00-00 | Cover Lock Assy 2 | 1 шт. | — | |
|
| 79 | 90269-06001-00 | Rivet | 4 шт. | — | |
|
| 80 | 4XY-2847R-00-00 | Damper 10 | 2 шт. | — | |
|
| 81 | 4XY-2847N-00-00 | Damper 8 | 1 шт. | — | |
|
| 82 | 4XY-2846P-00-00 | Plate 7 | 1 шт. | — | |
|
| 83 | 4XY-2849J-00-00 | Plate, Rubber 9 | 1 шт. | — | |
|
| 84 | 4XY-2846R-00-00 | Plate 8 | 1 шт. | — | |
|
| 85 | 4XY-2847T-00-00 | Plate, Rubber 11 | 1 шт. | — | |
|
| 86 | 92017-06016-00 | Bolt, Button Head | 6 шт. | — | |
|
| 87 | 92907-06600-00 | Washer, Plate | 4 шт. | — | |
|
| 88 | 4XY-2848H-00-00 | Seat | 1 шт. | — | |
|
| 89 | 4XY-28446-02-00 | Label, Caution | 1 шт. | — | |
|
| 90 | 4NK-21668-A0-00 | Label, Tire | 0 шт. | — | |
|
| 91 | 4LE-21686-A0-00 | Plate, Routing 2 FOR CALIFORNIA | 0 шт. | — | |
|
