| 1 | 4NK-12420-03-00 | Water Pump Assy | 1 шт. | — | |
|
| 2 | 1FK-12450-00-00 | . .Impeller Shaft Assy | 1 шт. | — | |
|
| 3 | 93603-14026-00 | . .Pin, Dowel | 1 шт. | — | |
|
| 4 | 26H-12459-00-00 | . .Gear, Impeller Shaft (31T) | 1 шт. | — | |
|
| 5 | 99009-10400-00 | . Circlip | 2 шт. | — | |
|
| 6 | 93306-00006-00 | . Bearing | 1 шт. | — | |
|
| 7 | 93101-10090-00 | . Oil Seal | 1 шт. | — | |
|
| 8 | 11H-12438-10-00 | . Seal, Mechanical | 1 шт. | — | |
|
| 9 | 4NK-W1241-02-00 | . .Cover, Housing | 1 шт. | — | |
|
| 10 | 93211-16591-00 | . .O-Ring | 1 шт. | — | |
|
| 11 | 91314-06030-00 | . Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 12 | 90340-14132-00 | . .Plug, Straight Screw | 1 шт. | — | |
|
| 13 | 214-11198-01-00 | . .Gasket | 1 шт. | — | |
|
| 14 | 90445-05278-00 | . .Hose (L200) | 1 шт. | — | |
|
| 15 | 353-13552-01-00 | . .Nozzle | 1 шт. | — | |
|
| 16 | 4NK-12449-00-00 | Gasket, Water Pump | 1 шт. | — | |
|
| 17 | 91314-06025-00 | Bolt, Hexagon Socket Head | 4 шт. | — | |
|
| 18 | 99530-10114-00 | Pin, Dowel | 2 шт. | — | |
|
| 19 | 91314-06080-00 | Bolt, Hexagon Socket Head | 3 шт. | — | |
|
| 20 | 4XY-12483-00-00 | Pipe 3 | 1 шт. | — | |
|
| 21 | 93210-23787-00 | O-Ring | 1 шт. | — | |
|
| 22 | 91314-06014-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 23 | 4XY-12417-00-00 | Housing, Thermostat | 1 шт. | — | |
|
| 24 | 90480-10517-00 | Grommet | 1 шт. | — | |
|
| 25 | 4XY-1244E-00-00 | Bracket 1 | 1 шт. | — | |
|
| 26 | 1AE-12410-00-00 | Thermostat Assy | 1 шт. | — | |
|
| 27 | 4XY-12413-00-00 | Cover, Thermostat | 1 шт. | — | |
|
| 28 | 93210-49046-00 | .O-Ring | 1 шт. | — | |
|
| 29 | 91317-06020-00 | Bolt | 2 шт. | — | |
|
