| 1 | 33D-12446-00-00 | Joint | 1 шт. | — | |
|
| 2 | 93210-24253-00 | O-Ring INCL. IN TOP END GASKET KIT | 1 шт. | — | |
|
| 3 | 95022-06020-00 | Bolt, Flange | 1 шт. | — | |
|
| 4 | 33D-12482-00-00 | Pipe 2 | 1 шт. | — | |
|
| 5 | 95022-06012-00 | Bolt, Flange | 1 шт. | — | |
|
| 6 | 93210-16500-00 | O-Ring INCL. IN BOTTOM END GASKET KIT | 1 шт. | — | |
|
| 7 | 33D-1240A-00-00 | Radiator Assy | 1 шт. | — | |
|
| 8 | 33D-12461-00-00 | Radiator Comp | 1 шт. | — | |
|
| 9 | 5SL-12462-00-00 | Cap, Radiator | 1 шт. | — | |
|
| 10 | 33D-12465-00-00 | Damper, Radiator | 3 шт. | — | |
|
| 11 | 91A20-05065-00 | Tube, Flexible Vinyl | 1 шт. | — | |
|
| 12 | 90467-090A2-00 | Clip | 1 шт. | — | |
|
| 13 | 33D-12576-00-00 | Hose 1 | 1 шт. | — | |
|
| 14 | 33D-12577-00-00 | Hose 2 | 1 шт. | — | |
|
| 15 | 33D-12578-00-00 | Hose 3 | 1 шт. | — | |
|
| 16 | 33D-12579-00-00 | Hose 4 | 1 шт. | — | |
|
| 17 | 90450-28001-00 | Hose Clamp Assy | 2 шт. | — | |
|
| 18 | 90450-25001-00 | Hose Clamp Assy | 3 шт. | — | |
|
| 19 | 90450-22001-00 | Hose Clamp Assy | 2 шт. | — | |
|
| 20 | 90450-32003-00 | Hose Clamp Assy | 1 шт. | — | |
|
| 21 | 90480-15012-00 | Grommet | 4 шт. | — | |
|
| 22 | 90387-06065-00 | Collar | 4 шт. | — | |
|
| 23 | 90105-06111-00 | Bolt, Flange | 4 шт. | — | |
|
| 24 | 90201-06571-00 | Washer, Plate | 4 шт. | — | |
|
| 25 | 90119-06239-00 | Bolt, With Washer | 2 шт. | — | |
|
