| 1 | 5EA-82100-11-00 | Battery Assy (Gs Gt14b-4) | 1 шт. | — | |
|
| 2 | 1MC-82116-00-00 | Wire, Minus Lead | 1 шт. | — | |
|
| 3 | 3D7-81940-00-00 | Starter Relay Assy (Rc19-076A) | 1 шт. | — | |
|
| 4 | 1AE-82151-00-00 | . .Fuse (30A-Bl) | 2 шт. | — | |
|
| 5 | 95022-06008-00 | Bolt, Flange | 2 шт. | — | |
|
| 6 | 2PD-82590-10-00 | Wire Harness Assy | 1 шт. | — | |
|
| 7 | 5JJ-82151-50-00 | . .Fuse (3A-Bl) | 2 шт. | — | |
|
| 8 | 5JJ-82151-00-00 | . .Fuse (7.5A-Bl) | 5 шт. | — | |
|
| 9 | 5JJ-82151-30-00 | . .Fuse (10A-Bl) | 4 шт. | — | |
|
| 10 | 5JJ-82151-10-00 | . .Fuse (15A-Bl) | 3 шт. | — | |
|
| 11 | 5JJ-82151-20-00 | . .Fuse (20A-Bl) | 4 шт. | — | |
|
| 12 | 5JJ-82151-60-00 | . .Fuse (30A-Bl) | 2 шт. | — | |
|
| 13 | 1MC-82151-00-00 | . .Fuse (1A-Bl) | 3 шт. | — | |
|
| 14 | 5JW-82151-10-00 | . .Fuse (50A) | 1 шт. | — | |
|
| 15 | 5JJ-82151-70-00 | . .Fuse (25A-Bl) | 2 шт. | — | |
|
| 16 | 1UA-82591-00-00 | Band | 1 шт. | — | |
|
| 17 | 90465-10098-00 | Clamp | 1 шт. | — | |
|
| 18 | 1UA-82591-00-00 | Band | 1 шт. | — | |
|
| 19 | 90464-12036-00 | Clamp | 1 шт. | — | |
|
| 20 | 5Y9-12491-00-00 | Clamp 1 | 1 шт. | — | |
|
| 21 | 90464-13073-00 | Clamp | 1 шт. | — | |
|
| 22 | 1MC-82509-00-00 | Wire, Sub Lead | 1 шт. | — | |
|
| 23 | 1D7-81960-01-00 | Rectifier & Regulator Assy | 1 шт. | — | |
|
| 24 | 95602-06200-00 | Nut, Self-Locking | 2 шт. | — | |
|
| 25 | 5VK-81950-30-00 | Relay Assy (5Vk-30) | 0 шт. | — | |
|
| 26 | 1ST-81950-00-00 | Relay Assy (1St-00) | 1 шт. | — | |
|
| 27 | 5JJ-81952-00-00 | . .Holder, Relay | 1 шт. | — | |
|
| 28 | 1ST-81950-00-00 | Relay Assy (1St-00) | 1 шт. | — | |
|
| 29 | 5JJ-81952-00-00 | . .Holder, Relay | 1 шт. | — | |
|
| 30 | 5DM-81950-00-00 | Relay Assy (G8hn-1C4t-Dj-Y52) | 1 шт. | — | |
|
| 31 | 5DM-81950-00-00 | Relay Assy (G8hn-1C4t-Dj-Y52) | 1 шт. | — | |
|
| 32 | 5DM-81950-00-00 | Relay Assy (G8hn-1C4t-Dj-Y52) | 1 шт. | — | |
|
| 33 | 5DM-81950-00-00 | Relay Assy (G8hn-1C4t-Dj-Y52) | 1 шт. | — | |
|
| 34 | 1TP-81950-00-00 | Relay Assy (1Tp-00) | 1 шт. | — | |
|
| 35 | 5EA-81952-00-00 | . .Holder, Relay | 1 шт. | — | |
|
| 36 | 1MC-82530-00-00 | Stop Switch Assy | 1 шт. | — | |
|
| 37 | 1MC-2144G-00-00 | Stay, Stop Switch | 1 шт. | — | |
|
| 38 | 98902-05008-00 | Screw, Bind | 1 шт. | — | |
|
| 39 | 5PS-82576-01-00 | Sensor, Lean Angle | 1 шт. | — | |
|
| 40 | 97702-40025-00 | Screw, Tapping | 2 шт. | — | |
|
| 41 | 90201-04030-00 | Washer, Plate | 2 шт. | — | |
|
| 42 | 4B4-84334-00-00 | Nut, Adjusting | 2 шт. | — | |
|
| 43 | 90464-12036-00 | Clamp | 1 шт. | — | |
|
| 44 | 90464-20213-00 | Clamp | 1 шт. | — | |
|
| 45 | 1MC-82566-00-00 | Switch, Side Stand | 1 шт. | — | |
|
| 46 | 90157-05008-00 | Screw, Pan Head | 2 шт. | — | |
|
| 47 | 3P6-8254B-00-00 | Terminal Comp | 1 шт. | — | |
|
| 48 | 5YU-85886-00-00 | Sensor, Air Temperature | 1 шт. | — | |
|
| 49 | 92012-05014-00 | Bolt, Button Head | 1 шт. | — | |
|
| 50 | 95702-05500-00 | Nut, Flange | 1 шт. | — | |
|
| 51 | 1MC-83371-00-00 | Horn | 1 шт. | — | |
|
| 52 | 92012-06010-00 | Bolt, Button Head | 1 шт. | — | |
|
| 53 | 3Y6-85130-02-00 | Rear Reflector Assy | 1 шт. | — | |
|
| 54 | 95602-05100-00 | .Nut, U | 1 шт. | — | |
|
| 55 | 90201-05043-00 | Washer, Plate | 1 шт. | — | |
|
| 56 | 11H-85110-01-00 | Reflector Assy | 2 шт. | — | |
|
| 57 | 95702-05500-00 | Nut, Flange | 2 шт. | — | |
|
| 58 | 2PD-85112-00-00 | Bracket, Reflector 1 | 1 шт. | — | |
|
| 59 | 2PD-85122-00-00 | Bracket, Reflector 2 | 1 шт. | — | |
|
| 60 | 449-85131-02-00 | Reflector, Rear 1 | 2 шт. | — | |
|
| 61 | 5JW-84751-00-00 | Bracket, License | 1 шт. | — | |
|
| 62 | 90201-06076-00 | Washer, Plate | 2 шт. | — | |
|
| 63 | 95602-06100-00 | Nut, Self-Locking | 2 шт. | — | |
|
| 64 | 90201-05036-00 | Washer, Plate | 2 шт. | — | |
|
