| 1 | 1MD-21511-00-P2 | Fender, Front DRMK | 1 шт. | — | |
|
| 2 | 90111-06043-00 | Bolt,Hex. Socket Button | 4 шт. | — | |
|
| 3 | 90387-065J6-00 | Collar | 4 шт. | — | |
|
| 4 | 90480-12072-00 | Grommet | 4 шт. | — | |
|
| 5 | 3WF-2153E-70-00 | Emblem, Yamaha | 1 шт. | — | |
|
| 6 | 1MD-21611-00-00 | Fender, Rear | 1 шт. | — | |
|
| 7 | 1MD-2160E-00-00 | Box | 1 шт. | — | |
|
| 8 | 90119-06159-00 | Bolt, With Washer | 4 шт. | — | |
|
| 9 | 90183-060A7-00 | Nut, Spring | 4 шт. | — | |
|
| 10 | 90387-06231-00 | Collar | 2 шт. | — | |
|
| 11 | 90201-07081-00 | Washer, Plate | 2 шт. | — | |
|
| 12 | 95802-06040-00 | Bolt, Flange | 2 шт. | — | |
|
| 13 | 90269-06081-00 | Rivet | 4 шт. | — | |
|
| 14 | 90338-08226-00 | Plug | 3 шт. | — | |
|
| 15 | 97702-60016-00 | Screw, Tapping | 3 шт. | — | |
|
| 16 | 5PS-2162A-00-00 | Hook | 1 шт. | — | |
|
| 17 | 4HM-2162A-00-00 | Hook | 2 шт. | — | |
|
| 18 | 90464-13185-00 | Clamp | 2 шт. | — | |
|
| 19 | 90267-40076-00 | Rivet, Blind | 6 шт. | — | |
|
| 20 | 92902-04200-00 | Washer, Plain | 2 шт. | — | |
|
| 21 | 36X-2811G-00-00 | Band | 1 шт. | — | |
|
| 22 | 4J2-82131-01-00 | Band, Battery | 1 шт. | — | |
|
| 23 | 5JW-21647-01-00 | Band | 2 шт. | — | |
|
| 24 | 3P6-21647-00-00 | Band | 1 шт. | — | |
|
| 25 | 5JW-21621-10-00 | Flap | 1 шт. | — | |
|
| 26 | 3P6-21651-00-P8 | Cover, Rear Fender DRMK | 1 шт. | — | |
|
| 27 | 3P6-2471K-00-P8 | Cover, Tail 1 DRMK | 1 шт. | — | |
|
| 28 | 3P6-2472K-00-P8 | Cover, Tail 2 DRMK | 1 шт. | — | |
|
| 29 | 90183-051A0-00 | .Nut, Spring | 4 шт. | — | |
|
| 30 | 90111-05044-00 | Bolt,Hex. Socket Button | 8 шт. | — | |
|
| 31 | 90202-05180-00 | Washer, Plate | 6 шт. | — | |
|
| 32 | 90183-050A0-00 | Nut, Spring | 4 шт. | — | |
|
| 33 | 90269-06081-00 | Rivet | 4 шт. | — | |
|
| 34 | 3P6-2163E-01-P7 | Cover, Rear Fender 2 DRMK | 2 шт. | — | |
|
| 35 | 3P6-2163E-11-P7 | Cover, Rear Fender 2 DRMK | 2 шт. | — | |
|
| 36 | 3P6-2163F-01-P7 | Cover, Rear Fender 3 DRMK | 2 шт. | — | |
|
| 37 | 3P6-21649-00-00 | Damper | 2 шт. | — | |
|
| 38 | 1MC-2163A-00-00 | Cover, Rear Fender 1 | 1 шт. | — | |
|
| 39 | 90269-06081-00 | Rivet | 2 шт. | — | |
|
| 40 | 97702-50125-00 | Screw, Tapping | 1 шт. | — | |
|
| 41 | 13S-21684-10-00 | Plate, Routing FOR CALIFORNIA | 0 шт. | — | |
|
| 42 | 1MC-21686-00-00 | Plate, Routing 2 FOR CALIFORNIA | 0 шт. | — | |
|
| 43 | 1MC-28100-00-00 | Tool Kit | 1 шт. | — | |
|
| 44 | 5JW-W9390-00-00 | Fjr Protect Sticker Set | 0 шт. | — | |
|
