| 1 | 36X-12171-00-00 | Camshaft 1 | 1 шт. | — | |
|
| 2 | 1KH-12176-00-00 | Sprocket, Cam Chain | 1 шт. | — | |
|
| 3 | 93604-10011-00 | Pin, Dowel | 1 шт. | — | |
|
| 4 | 90101-10303-00 | Bolt | 1 шт. | — | |
|
| 5 | 90201-10591-00 | Washer, Plate | 1 шт. | — | |
|
| 6 | 90387-255F3-00 | Collar | 1 шт. | — | |
|
| 7 | 94580-41104-00 | Chain (Did25sh 104L) | 1 шт. | — | |
|
| 8 | 5H0-12231-00-00 | Guide, Stopper 1 | 1 шт. | — | |
|
| 9 | 5N0-12241-00-00 | Guide, Stopper 2 | 1 шт. | — | |
|
| 10 | 3GC-12210-10-00 | Tensioner Assy, Cam Chain | 1 шт. | — | |
|
| 11 | 4FM-12213-00-00 | Gasket, Tensioner Case | 1 шт. | — | |
|
| 12 | 91317-06025-00 | Bolt,Hex.Socket Head | 2 шт. | — | |
|
| 13 | 97027-06016-00 | Bolt, Hexagon | 2 шт. | — | |
|
| 14 | 92907-06600-00 | Washer, Plate | 2 шт. | — | |
|
