| 1 | 43541-14J10 | BRACKET,FR FOOTREST NO.1 RH | 1 шт. | — | |
|
| 2 | 43551-14J10 | BRACKET,FR FOOTREST NO.1 LH | 1 шт. | — | |
|
| 4 | 43511-14J10 | BRACKET,FR FOOTREST NO.2 RH | 1 шт. | — | |
|
| 5 | 43521-47H20 | BRACKET,FR FOOTREST NO.2 LH | 1 шт. | — | |
|
| 6 | 43516-37H10 | BAR,FRONT FOOTREST,R | 1 шт. | — | |
|
| 7 | 43526-37H10 | BAR,FRONT FOOTREST,L | 1 шт. | — | |
|
| 8 | 43531-41G20 | HOLDER,FOOTREST | 1 шт. | — | |
|
| 9 | 09106-10064 | BOLT (10X28) | 1 шт. | — | |
|
| 10 | 09208-08018 | PIN | 2 шт. | — | |
|
| 11 | 43581-47H00 | SPRING,FRONT FOOTREST | 2 шт. | — | |
|
| 13 | 43576-07D10 | BOLT,BANK SENSOR | 2 шт. | — | |
|
| 14 | 43576-47H40 | GUARD, FOOTREST LH | 1 шт. | — | |
|
| 15 | 43571-47H30 | GUARD, FOOTREST RH | 1 шт. | — | |
|
| 16 | 43577-35F10 | SCREW,FOOTREST GUARD LH | 2 шт. | — | |
|
| 17 | 43600-14J30 | FOOTREST, PILLION RH | 1 шт. | — | |
|
| 18 | 43611-37H30 | .BAR,PILLION FOOTREST,R | 1 шт. | — | |
|
| 22 | 43816-47H00 | .PLATE,PILLION FOOTREST RH | 1 шт. | — | |
|
| 26 | 43700-14J30 | FOOTREST, PILLION LH | 1 шт. | — | |
|
| 27 | 43621-37H30 | .BAR,PILLION FOOTREST,L | 1 шт. | — | |
|
| 28 | 09208-08020 | .PIN | 1 шт. | — | |
|
| 28 | 09208-08020 | .PIN | 1 шт. | — | |
|
| 29 | 09440-05003 | SPRING | 1 шт. | — | |
|
| 29 | 09440-05003 | SPRING | 1 шт. | — | |
|
| 30 | 06111-07004 | BALL | 1 шт. | — | |
|
| 30 | 06111-07004 | BALL | 1 шт. | — | |
|
| 31 | 43826-47H00 | .PLATE,PILLION FOOTREST LH | 1 шт. | — | |
|
| 32 | 08332-1106A | E-RING | 2 шт. | — | |
|
| 32 | 08332-1106A | E-RING | 1 шт. | — | |
|
| 32 | 08332-1106A | E-RING | 1 шт. | — | |
|
| 33 | 09280-08013 | .O-RING (D:2.4,ID:6.9) | 1 шт. | — | |
|
| 33 | 09280-08013 | .O-RING (D:2.4,ID:6.9) | 1 шт. | — | |
|
| 34 | 09160-08091 | .WASHER (8.5X14X1.0) | 1 шт. | — | |
|
| 34 | 09160-08091 | .WASHER (8.5X14X1.0) | 1 шт. | — | |
|
| 35 | 09106-08186 | BOLT (8X23) | 8 шт. | — | |
|
| 35 | 09106-08186 | BOLT (8X23) | 4 шт. | — | |
|
