| 1 | 2S3-16150-00-00 | Primary Driven Gear Comp | 1 шт. | — | |
|
| 2 | 2S3-13324-00-00 | . Gear, Pump Drive | 1 шт. | — | |
|
| 3 | 93604-16092-00 | . Pin, Dowel | 3 шт. | — | |
|
| 4 | 93440-57M01-00 | . Circlip | 1 шт. | — | |
|
| 5 | 4B1-16154-00-00 | Plate, Thrust 1 | 1 шт. | — | |
|
| 6 | 90208-25002-00 | Washer, Conical Spring | 1 шт. | — | |
|
| 7 | 2S3-16360-00-00 | Pressure Plate Assy 2 | 1 шт. | — | |
|
| 8 | 2S3-16370-00-00 | Clutch Boss Assy | 1 шт. | — | |
|
| 10 | 5YU-16321-00-00 | Plate, Friction | 10 шт. | — | |
|
| 11 | 2S3-16351-00-00 | Plate, Pressure 1 | 1 шт. | — | |
|
| 12 | 93306-00304-00 | Bearing | 1 шт. | — | |
|
| 13 | 5YU-16334-00-00 | Spring, Clutch 2 | 1 шт. | — | |
|
| 14 | 36Y-16335-00-00 | Housing, Spring | 1 шт. | — | |
|
| 15 | 2S3-16353-00-00 | Plate, Pressure 3 | 1 шт. | — | |
|
| 16 | 97002-06025-00 | Bolt | 6 шт. | — | |
|
| 17 | 2S3-16539-00-00 | Spring | 4 шт. | — | |
|
| 19 | 47X-16324-00-00 | Plate, Clutch 1 UR (T1.6) | 1 шт. | — | |
|
| 19 | 2H7-16324-00-00 | Plate, Clutch 1 UR (T2.6) | 1 шт. | — | |
|
| 19 | 2H7-16324-00-00 | Plate, Clutch 1 UR (T2.6) | 1 шт. | — | |
|
| 19 | 2H7-16325-00-00 | Plate, Clutch 2 (T2.0) | 7 шт. | — | |
|
| 19 | 2H7-16325-00-00 | Plate, Clutch 2 UR (T2.0) | 1 шт. | — | |
|
| 19 | 2H7-16325-00-00 | Plate, Clutch 2 UR (T2.0) | 1 шт. | — | |
|
| 20 | 5VY-16164-00-00 | Plate, Thrust 2 | 1 шт. | — | |
|
| 21 | 90387-25026-00 | Collar | 1 шт. | — | |
|
| 22 | 93310-33559-00 | Bearing | 1 шт. | — | |
|
| 23 | 2S3-16377-00-00 | Nut, Lock | 1 шт. | — | |
|
| 24 | 4KG-16356-00-00 | Rod, Push 1 | 1 шт. | — | |
|
| 25 | 93210-06632-00 | O-Ring | 1 шт. | — | |
|
| 26 | 93511-32017-00 | Ball | 1 шт. | — | |
|
| 27 | 2S3-16357-00-00 | Rod, Push 2 | 1 шт. | — | |
|
| 28 | 93102-08008-00 | Oil Seal | 1 шт. | — | |
|
| 29 | 2S3-16381-00-00 | Push Lever Comp | 1 шт. | — | |
|
| 30 | 2S3-1638G-00-00 | . Cup | 1 шт. | — | |
|
| 31 | 2S3-1638J-00-00 | . Boot | 1 шт. | — | |
|
| 32 | 90110-06246-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 33 | 99530-08012-00 | Pin, Dowel | 2 шт. | — | |
|
| 34 | 2S3-15645-00-00 | Plate | 1 шт. | — | |
|
