| 1 | 1S4-82100-10-00 | Battery Assy (Ytz7s) | 1 шт. | — | |
|
| 2 | 5XT-82116-00-00 | Wire, Minus Lead | 1 шт. | — | |
|
| 3 | 5XT-82131-00-00 | Band, Battery | 1 шт. | — | |
|
| 4 | 5XT-82171-00-00 | Stay, Fuse Box | 1 шт. | — | |
|
| 5 | 3C5-82501-10-00 | Main Switch Steering Lock | 1 шт. | — | |
|
| 6 | 4BH-82511-09-00 | Blank Key AP | 1 шт. | — | |
|
| 7 | 90109-08195-00 | Bolt | 2 шт. | — | |
|
| 8 | 5C1-82530-00-00 | Stop Switch Assy | 1 шт. | — | |
|
| 9 | 1YB-82590-00-00 | Wire Harness Assy | 1 шт. | — | |
|
| 10 | 5JJ-82151-30-00 | . .Fuse (10A-Bl) | 4 шт. | — | |
|
| 11 | 5JJ-82151-10-00 | . .Fuse (15A-Bl) | 2 шт. | — | |
|
| 12 | 4WA-81980-00-00 | . .Diode Assy | 1 шт. | — | |
|
| 13 | 3XV-81980-00-00 | . .Diode Assy | 1 шт. | — | |
|
| 14 | 4YR-81940-02-00 | Starter Relay Assy (Rc19-018) | 1 шт. | — | |
|
| 15 | 1AE-82151-00-00 | . .Fuse (30A-Bl) | 2 шт. | — | |
|
| 16 | 95027-06008-00 | Bolt, Flange | 1 шт. | — | |
|
| 17 | 5XT-82115-00-00 | Wire, Plus Lead | 1 шт. | — | |
|
| 18 | 95027-06008-00 | Bolt, Flange | 1 шт. | — | |
|
| 19 | 5VU-82576-01-00 | Sensor, Lean Angle | 0 шт. | — | |
|
| 20 | 90201-047A2-00 | Washer, Plate | 2 шт. | — | |
|
| 21 | 91312-04025-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 22 | 5XT-2141A-00-00 | Bracket 1 | 1 шт. | — | |
|
| 23 | 95022-06012-00 | Bolt, Flange | 1 шт. | — | |
|
| 24 | 1ST-81950-00-00 | Relay Assy (1St-00) | 1 шт. | — | |
|
| 25 | 5JJ-81952-00-00 | . .Holder, Relay | 1 шт. | — | |
|
| 26 | 5UM-81950-E0-00 | Relay Assy (5Um-E0) | 2 шт. | — | |
|
| 27 | 5XT-81952-00-00 | Holder, Relay | 1 шт. | — | |
|
| 28 | 5XT-82566-00-00 | Switch, Side Stand | 1 шт. | — | |
|
| 29 | 90110-05227-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 30 | 90464-10190-00 | Clamp | 1 шт. | — | |
|
| 31 | 90464-08189-00 | Clamp | 1 шт. | — | |
|
| 32 | 90464-05188-00 | Clamp | 1 шт. | — | |
|
| 33 | 90464-16006-00 | Clamp | 2 шт. | — | |
|
| 34 | 1UA-82591-00-00 | .Band | 1 шт. | — | |
|
| 35 | 90464-13073-00 | Clamp | 1 шт. | — | |
|
| 36 | 1UA-82591-00-00 | .Band | 1 шт. | — | |
|
| 37 | 1UA-82591-00-00 | .Band | 1 шт. | — | |
|
| 38 | 3TB-83936-00-00 | Band, Switch Cord | 1 шт. | — | |
|
| 39 | 90464-13077-00 | Clamp | 1 шт. | — | |
|
| 40 | 1UA-82591-00-00 | .Band | 2 шт. | — | |
|
| 41 | 90464-20191-00 | Clamp | 1 шт. | — | |
|
| 42 | 90465-10098-00 | Clamp | 2 шт. | — | |
|
| 43 | 90464-10190-00 | Clamp | 1 шт. | — | |
|
| 44 | 1UA-82591-00-00 | .Band | 2 шт. | — | |
|
| 45 | 1UA-82591-00-00 | .Band | 1 шт. | — | |
|
| 46 | 90464-13077-00 | Clamp | 1 шт. | — | |
|
| 47 | 90464-16001-00 | Clamp | 1 шт. | — | |
|
| 48 | 90465-10098-00 | Clamp | 1 шт. | — | |
|
| 49 | 2D1-82589-00-00 | Protecter, Wire Harness | 0 шт. | — | |
|
| 50 | 90465-10098-00 | Clamp | 1 шт. | — | |
|
| 51 | 5VN-24188-00-00 | Mold, Fuel Tank | 1 шт. | — | |
|
| 52 | 1UA-82591-00-00 | .Band | 1 шт. | — | |
|
