| 1 | 3D7-21110-11-00 | Frame Comp | 1 шт. | — | |
|
| 2 | 3D7-21280-10-00 | Downtube Comp | 1 шт. | — | |
|
| 3 | 90111-12001-00 | Bolt, Hex. Socket Button | 2 шт. | — | |
|
| 4 | 90179-12657-00 | Nut | 2 шт. | — | |
|
| 5 | 90201-12044-00 | Washer, Plate | 2 шт. | — | |
|
| 6 | 3D7-21481-00-00 | Bolt, Engine Mounting 1 | 2 шт. | — | |
|
| 7 | 90179-12657-00 | Nut | 2 шт. | — | |
|
| 8 | 90201-12044-00 | Washer, Plate | 2 шт. | — | |
|
| 9 | 32C-21190-10-00 | Rear Frame Comp | 1 шт. | — | |
|
| 10 | 90105-10246-00 | Bolt, Flange | 2 шт. | — | |
|
| 11 | 90105-10244-00 | Bolt, Flange | 2 шт. | — | |
|
| 12 | 90201-10057-00 | Washer, Plate | 4 шт. | — | |
|
| 13 | 90105-10012-00 | Bolt, Flange | 1 шт. | — | |
|
| 14 | 90201-11015-00 | Washer, Plate | 1 шт. | — | |
|
| 15 | 90105-10226-00 | Bolt, Flange | 1 шт. | — | |
|
| 16 | 90105-10228-00 | Bolt, Flange | 1 шт. | — | |
|
| 17 | 90179-10658-00 | Nut | 3 шт. | — | |
|
| 18 | 3D7-21447-00-00 | Bracket, Footrest | 2 шт. | — | |
|
| 19 | 90149-10031-00 | .Screw | 4 шт. | — | |
|
| 20 | 3D7-2133F-00-00 | Bracket, Master Cylinder | 1 шт. | — | |
|
| 21 | 92012-08014-00 | Bolt, Button Head | 2 шт. | — | |
|
| 22 | 3D7-21441-00-00 | Bracket, Stop Switch | 1 шт. | — | |
|
| 23 | 95022-06010-00 | Bolt, Flange | 1 шт. | — | |
|
| 24 | 3D7-21451-00-00 | Hook, Spring | 1 шт. | — | |
|
| 25 | 92012-06010-00 | Bolt, Button Head | 1 шт. | — | |
|
| 26 | 3D7-2142K-00-00 | Bracket, Radiator | 1 шт. | — | |
|
| 27 | 95022-06012-00 | .Bolt, Flange | 2 шт. | — | |
|
| 28 | 3D7-21321-00-00 | Stay, Side Cover 1 | 1 шт. | — | |
|
| 29 | 90111-08072-00 | Bolt, Hex. Socket Button | 2 шт. | — | |
|
| 30 | 3TB-22178-00-00 | Tensioner | 1 шт. | — | |
|
| 31 | 10V-22184-00-00 | Bush | 1 шт. | — | |
|
| 32 | 90387-08024-00 | Collar | 1 шт. | — | |
|
| 33 | 95022-08040-00 | Bolt, Flange | 1 шт. | — | |
|
| 34 | 90201-08045-00 | Washer, Plate | 1 шт. | — | |
|
| 35 | 30X-22178-00-00 | Tensioner | 1 шт. | — | |
|
| 36 | 10V-22184-00-00 | Bush | 1 шт. | — | |
|
| 37 | 90387-08024-00 | Collar | 1 шт. | — | |
|
| 38 | 95022-08040-00 | Bolt, Flange | 1 шт. | — | |
|
| 39 | 90201-08045-00 | Washer, Plate | 2 шт. | — | |
|
| 40 | 3D7-2147A-00-00 | Guard, Engine 1 | 1 шт. | — | |
|
| 41 | 90119-06217-00 | Bolt, With Washer | 1 шт. | — | |
|
| 42 | 3D7-2147E-00-00 | Guard, Engine 2 | 1 шт. | — | |
|
| 43 | 90119-06217-00 | Bolt, With Washer | 1 шт. | — | |
|
| 44 | 4R8-21308-01-00 | Helmet Hanger Assy | 1 шт. | — | |
|
| 45 | 90151-06067-00 | Screw, Countersunk | 1 шт. | — | |
|
| 46 | 3D7-2139X-00-00 | Damper | 2 шт. | — | |
|
| 47 | 3MA-82591-00-00 | Band | 1 шт. | — | |
|
| 48 | 90464-16061-00 | Clamp | 1 шт. | — | |
|
| 49 | 3D7-2117F-00-00 | Cover | 1 шт. | — | |
|
| 50 | 3D7-2117M-00-00 | Cover 2 | 2 шт. | — | |
|
| 51 | 90465-10098-00 | Clamp | 2 шт. | — | |
|
| 52 | 3D7-2117N-00-00 | Cover 3 | 1 шт. | — | |
|
| 53 | 3D7-2117R-00-00 | Cover 4 | 1 шт. | — | |
|
| 54 | 3D7-21288-00-00 | Guide, Cable | 1 шт. | — | |
|
| 55 | 92017-06010-00 | Bolt, Button Head | 1 шт. | — | |
|
| 56 | 3D7-21339-00-00 | Guide, Wire | 1 шт. | — | |
|
| 57 | 92017-06010-00 | Bolt, Button Head | 1 шт. | — | |
|
| 58 | 3D7-21161-00-00 | Holder, Cable FOR U49 | 1 шт. | — | |
|
| 59 | 3D7-21161-10-00 | Holder, Cable FOR CALIFORNIA | 0 шт. | — | |
|
| 60 | 95027-06010-00 | Bolt, Flange | 1 шт. | — | |
|
| 61 | 3D7-21162-00-00 | Holder, Clutch Cable | 1 шт. | — | |
|
| 62 | 92017-06010-00 | Bolt, Button Head | 1 шт. | — | |
|
| 63 | 5XT-25839-10-00 | Label, Brake Fluid | 1 шт. | — | |
|
| 64 | 2N4-21717-00-00 | Damper | 1 шт. | — | |
|
| 65 | 90338-16148-00 | Plug | 2 шт. | — | |
|
| 66 | 3D7-2163A-00-00 | Cover, Rear Fender 1 | 0 шт. | — | |
|
| 67 | 90464-16061-00 | Clamp | 1 шт. | — | |
|
| 68 | 3D7-21773-00-00 | Grommet | 1 шт. | — | |
|
| 69 | 3D7-28100-00-00 | Tool Kit | 1 шт. | — | |
|
| 70 | 4GY-21107-10-00 | Tool Box Comp | 1 шт. | — | |
|
| 71 | 120-82131-00-00 | Band, Battery | 1 шт. | — | |
|
| 72 | 90338-09130-00 | Plug | 1 шт. | — | |
|
| 73 | 90480-10017-00 | Grommet | 1 шт. | — | |
|
| 74 | 3D7-8252U-00-00 | Cover | 1 шт. | — | |
|
| 75 | 90464-16061-00 | Clamp | 2 шт. | — | |
|
| 76 | 3D7-2117T-00-00 | Cover 5 | 1 шт. | — | |
|
| 77 | 3D7-2117U-00-00 | Cover 6 | 1 шт. | — | |
|
| 78 | 3D7-2117W-00-00 | Cover 8 | 2 шт. | — | |
|
| 79 | 90338-15004-00 | Plug | 1 шт. | — | |
|
