| 1 | 1WS-15411-00-00 | Cover, Crankcase 1 | 1 шт. | — | |
|
| 2 | 90340-36005-00 | Plug, Straight Screw | 1 шт. | — | |
|
| 3 | 93210-357A3-00 | O-Ring | 1 шт. | — | |
|
| 4 | 92017-08012-00 | Bolt, Button Head | 1 шт. | — | |
|
| 5 | 90430-08143-00 | Gasket | 1 шт. | — | |
|
| 6 | 1WS-15451-00-00 | Gasket, Crankcase Cover 1 | 1 шт. | — | |
|
| 10 | 1WS-15418-00-00 | Cover, Chain Case | 1 шт. | — | |
|
| 11 | 1WS-15377-00-00 | Guide, Inlet | 1 шт. | — | |
|
| 12 | 90110-06395-00 | Bolt, Hexagon Socket Head | 3 шт. | — | |
|
| 13 | 1WS-15461-00-00 | Gasket, Crankcase Cover 2 INCL. IN CLUCH PLATE KIT | 1 шт. | — | |
|
| 14 | 99530-08012-00 | Pin, Dowel | 2 шт. | — | |
|
| 14 | 99530-08012-00 | Pin, Dowel | 2 шт. | — | |
|
| 15 | 90110-06388-00 | Bolt, Hexagon Socket Head | 8 шт. | — | |
|
| 15 | 90110-06388-00 | Bolt, Hexagon Socket Head | 10 шт. | — | |
|
| 16 | 90465-08045-00 | Clamp | 2 шт. | — | |
|
| 17 | 1WS-15441-00-00 | Holder, Clutch Cable | 1 шт. | — | |
|
| 18 | 90110-06389-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 18 | 90110-06389-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 19 | 3F9-15362-10-00 | Plug, Oil Level | 1 шт. | — | |
|
| 20 | 93210-27194-00 | O-Ring | 1 шт. | — | |
|
| 21 | 1WS-15421-00-00 | .Cover, Crankcase 2 | 1 шт. | — | |
|
