| 1 | 1WS-12461-00-00 | Radiator Comp | 1 шт. | — | |
|
| 2 | 1WS-12405-00-00 | Blower Assy | 1 шт. | — | |
|
| 3 | 1WS-12671-00-00 | Nut 1 | 6 шт. | — | |
|
| 4 | 5GJ-12675-00-00 | Bolt, Blower Holding | 3 шт. | — | |
|
| 5 | 90480-15363-00 | Grommet | 3 шт. | — | |
|
| 6 | 90387-07391-00 | Collar | 1 шт. | — | |
|
| 7 | 95802-06025-00 | Bolt, Flange | 0 шт. | — | |
|
| 8 | 3D7-12462-00-00 | Cap, Radiator | 1 шт. | — | |
|
| 9 | 91317-03006-00 | Bolt, Hex. Socket Head | 1 шт. | — | |
|
| 10 | 1WS-12578-00-00 | Hose 3 | 1 шт. | — | |
|
| 11 | 90467-290A0-00 | Clip | 1 шт. | — | |
|
| 12 | 90450-35001-00 | Hose Clamp Assy | 1 шт. | — | |
|
| 13 | 1WS-21871-00-00 | Tank, Recovery | 1 шт. | — | |
|
| 14 | 26H-21828-00-00 | Elbow | 1 шт. | — | |
|
| 15 | 90445-08020-00 | Hose | 1 шт. | — | |
|
| 16 | 3P6-21875-00-00 | Cap | 1 шт. | — | |
|
| 17 | 90467-08075-00 | Clip | 1 шт. | — | |
|
| 18 | 1WS-21816-00-00 | Pipe 1 | 1 шт. | — | |
|
| 19 | 4XY-14568-00-00 | Joint | 1 шт. | — | |
|
| 20 | 1WS-2172W-00-00 | Cover | 1 шт. | — | |
|
| 21 | 90269-06008-00 | Rivet | 1 шт. | — | |
|
| 22 | 90387-06024-00 | Collar | 1 шт. | — | |
|
| 23 | 90110-06163-00 | Bolt, Hexagon Socket Head | 1 шт. | — | |
|
| 24 | 90467-08075-00 | Clip | 1 шт. | — | |
|
| 25 | 90467-08003-00 | Clip | 1 шт. | — | |
|
| 26 | 90445-11M08-00 | Hose (L10) | 1 шт. | — | |
|
| 27 | 90464-07M40-00 | Clamp | 1 шт. | — | |
|
| 28 | 1WS-21731-00-00 | Cover, Side 3 | 1 шт. | — | |
|
| 29 | 1WS-21741-00-00 | Cover, Side 4 | 1 шт. | — | |
|
| 30 | 90387-06130-00 | Collar | 4 шт. | — | |
|
| 31 | 90111-06151-00 | Bolt, Hex. Socket Button | 4 шт. | — | |
|
