| 1 | 1RC-25338-00-P0 | Cast Wheel, Rear UR DPBM15 FOR MS1 | 0 шт. | — | |
|
| 2 | 1RC-25338-00-98 | Cast Wheel, Rear UR LGB FOR SMX | 1 шт. | — | |
|
| 3 | 93306-20480-00 | Bearing | 1 шт. | — | |
|
| 4 | 93102-28022-00 | Oil Seal | 1 шт. | — | |
|
| 5 | 93306-00416-00 | Bearing | 1 шт. | — | |
|
| 6 | 2PP-25317-00-00 | Spacer, Bearing | 1 шт. | — | |
|
| 7 | 5SL-25364-00-00 | Damper | 6 шт. | — | |
|
| 8 | 94118-17080-00 | Tire (180/55Zr17 M/C 73W) UR BRIDGESTONE | 1 шт. | — | |
|
| 9 | 93900-00030-00 | Valve, Rim (Tr412) TAIHEIYO | 1 шт. | — | |
|
| 10 | 5MT-25398-10-00 | Balancer, Wheel (20G) UN | 1 шт. | — | |
|
| 11 | 5MT-25398-20-00 | Balancer, Wheel (30G) UN | 1 шт. | — | |
|
| 12 | 5MT-25398-00-00 | Balancer, Wheel (10G) UN | 1 шт. | — | |
|
| 13 | 5JJ-25366-00-00 | Clutch, Hub | 1 шт. | — | |
|
| 14 | 93306-205B5-00 | Bearing | 1 шт. | — | |
|
| 15 | 1RC-25383-00-00 | Collar, Wheel | 1 шт. | — | |
|
| 16 | 93106-40013-00 | Oil Seal | 1 шт. | — | |
|
| 17 | 1WS-25443-00-00 | Sprocket, Driven (43T) | 1 шт. | — | |
|
| 18 | 90116-10048-00 | Bolt, Stud | 6 шт. | — | |
|
| 19 | 95602-10200-00 | Nut, S/L Flange | 6 шт. | — | |
|
| 20 | 1WS-2537W-00-00 | Bracket 1 | 1 шт. | — | |
|
| 21 | 90201-10045-00 | Washer, Plate | 6 шт. | — | |
|
| 22 | 90387-20036-00 | Collar | 1 шт. | — | |
|
| 23 | 90387-20035-00 | Collar | 1 шт. | — | |
|
| 24 | 94582-40108-00 | Chain (Did 525Vz-108Le) | 1 шт. | — | |
|
| 25 | 1WS-25388-00-00 | Puller, Chain 1 | 2 шт. | — | |
|
| 26 | 1WS-22174-00-00 | End 1 | 1 шт. | — | |
|
| 27 | 1WS-22175-00-00 | End 1 | 1 шт. | — | |
|
| 28 | 95302-08600-00 | Nut, Hexagon | 4 шт. | — | |
|
| 29 | 92902-08600-00 | Washer, Plate | 2 шт. | — | |
|
| 30 | 4FN-22141-00-00 | Shaft, Pivot | 1 шт. | — | |
|
| 31 | 90185-18009-00 | Nut, Self-Locking | 1 шт. | — | |
|
| 32 | 90201-18021-00 | Washer, Plate | 1 шт. | — | |
|
| 33 | 1WS-2538D-00-00 | Cover, Rear Axle 1 UR FOR SMX, MS1 | 1 шт. | — | |
|
| 34 | 1WS-2538N-00-00 | Cover, Rear Axle 2 UR FOR SMX, MS1 | 1 шт. | — | |
|
