| 1 | 1WS-274A4-00-00 | Bracket, Adapter 2 | 1 шт. | — | |
|
| 2 | 90111-10060-00 | Bolt, Hex. Socket Button | 2 шт. | — | |
|
| 3 | 90465-08045-00 | Clamp | 1 шт. | — | |
|
| 4 | 95022-06010-00 | Bolt, Flange | 1 шт. | — | |
|
| 5 | 1WS-27461-00-00 | Footrest | 1 шт. | — | |
|
| 6 | 91701-08040-00 | Pin | 1 шт. | — | |
|
| 7 | 91402-25015-00 | Pin, Cotter | 1 шт. | — | |
|
| 8 | 90508-18056-00 | Spring, Torsion | 1 шт. | — | |
|
| 9 | 3YX-27413-00-00 | Cover, Footrest | 1 шт. | — | |
|
| 10 | 90157-05025-00 | Screw, Pan Head | 2 шт. | — | |
|
| 11 | 90109-086F8-00 | Bolt | 1 шт. | — | |
|
| 12 | 1WS-27443-00-00 | Bracket 3 UR FOR SMX, MS1 | 1 шт. | — | |
|
| 13 | 36Y-27414-00-00 | Damper, Footrest | 2 шт. | — | |
|
| 14 | 5VX-27114-00-00 | Stopper, Main Stand | 1 шт. | — | |
|
| 15 | 1WS-27446-00-00 | Plate 2 UR FOR SMX, MS1 | 1 шт. | — | |
|
| 16 | 92014-08025-00 | Bolt, Button Head | 2 шт. | — | |
|
| 17 | 1WS-27211-00-00 | Pedal, Brake | 1 шт. | — | |
|
| 18 | 1WS-18113-00-00 | Cover, Shift Pedal | 1 шт. | — | |
|
| 19 | 90206-12074-00 | Washer, Wave | 1 шт. | — | |
|
| 20 | 4BP-27434-01-00 | Bolt | 1 шт. | — | |
|
| 21 | 90201-12051-00 | Washer, Plate | 1 шт. | — | |
|
| 22 | 90201-08053-00 | Washer, Plate | 1 шт. | — | |
|
| 23 | 90506-23008-00 | Spring, Tension | 1 шт. | — | |
|
| 24 | 90110-08071-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 25 | 90209-08295-00 | Washer | 2 шт. | — | |
|
| 26 | 1WS-27463-00-00 | Cover 2 UR FOR SMX, MS1 | 1 шт. | — | |
|
| 27 | 90480-14003-00 | Grommet | 2 шт. | — | |
|
| 28 | 90387-06057-00 | Collar | 2 шт. | — | |
|
| 29 | 90149-06105-00 | Screw | 2 шт. | — | |
|
| 30 | 1WS-27425-00-00 | Bracket, Footrest 2 | 1 шт. | — | |
|
| 31 | 95802-06010-00 | Bolt, Flange | 1 шт. | — | |
|
| 32 | 90269-08008-00 | Rivet | 1 шт. | — | |
|
| 33 | 1WS-27475-00-P0 | Cap 1 MBL2 | 1 шт. | — | |
|
| 34 | 3VR-27441-02-00 | Footrest, Rear 2 | 1 шт. | — | |
|
| 35 | 1WS-2742L-01-00 | Bracket 5 | 1 шт. | — | |
|
| 36 | 90501-12743-00 | Spring, Compression | 1 шт. | — | |
|
| 37 | 93501-04011-00 | Ball | 1 шт. | — | |
|
| 38 | 5VX-27437-00-00 | Washer, Special | 1 шт. | — | |
|
| 39 | 91702-08040-00 | Pin, Clevis | 1 шт. | — | |
|
| 40 | 91401-25015-00 | Pin, Cotter | 1 шт. | — | |
|
| 41 | 90110-08231-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
