| 1 | 3GW-27410-20-00 | Front Footrest Assy (Left) | 1 шт. | — | |
|
| 2 | 90109-08018-00 | . Bolt | 1 шт. | — | |
|
| 3 | 1JK-27413-00-00 | . .Cover, Footrest | 1 шт. | — | |
|
| 4 | 90157-05079-00 | . Screw, Pan Head | 2 шт. | — | |
|
| 5 | 3GW-27420-20-00 | Front Footrest Assy (Right) | 1 шт. | — | |
|
| 6 | 90109-08018-00 | . Bolt | 1 шт. | — | |
|
| 7 | 1JK-27413-00-00 | . .Cover, Footrest | 1 шт. | — | |
|
| 8 | 90157-05079-00 | . Screw, Pan Head | 2 шт. | — | |
|
| 9 | 2J2-27416-10-00 | Bolt, Footrest | 2 шт. | — | |
|
| 10 | 2J2-27414-01-00 | Damper, Footrest | 4 шт. | — | |
|
| 11 | 90209-12102-00 | Washer | 4 шт. | — | |
|
| 12 | 90201-08043-00 | Washer, Plate | 4 шт. | — | |
|
| 13 | 90176-08068-00 | Nut, Crown | 4 шт. | — | |
|
| 14 | 3GW-27432-00-33 | Bracket 1 (0033,Yb) YB | 1 шт. | — | |
|
| 15 | 95807-10020-00 | Bolt, Flange | 2 шт. | — | |
|
| 16 | 3HT-27442-00-00 | Bracket 2 | 1 шт. | — | |
|
| 17 | 95607-12200-00 | Nut, Self-Locking | 1 шт. | — | |
|
| 18 | 90201-12027-00 | Washer, Plate | 1 шт. | — | |
|
| 19 | 4BR-27431-01-00 | Footrest, Rear 1 | 1 шт. | — | |
|
| 20 | 4BR-27441-01-00 | Footrest, Rear 2 | 1 шт. | — | |
|
| 21 | 2GH-27413-00-00 | Cover, Footrest | 2 шт. | — | |
|
| 22 | 90501-15001-00 | Spring, Compression | 2 шт. | — | |
|
| 23 | 93501-04011-00 | Ball | 2 шт. | — | |
|
| 24 | 95027-06035-00 | Bolt, Flange | 2 шт. | — | |
|
| 25 | 95607-06100-00 | Nut, Self-Locking | 2 шт. | — | |
|
| 26 | 90387-064H8-00 | Collar | 2 шт. | — | |
|
| 27 | 98507-05010-00 | Screw, Pan Head | 4 шт. | — | |
|
| 28 | 2J2-27111-00-00 | Stand, Main | 1 шт. | — | |
|
| 29 | 90109-102G9-00 | Bolt | 2 шт. | — | |
|
| 30 | 90506-45002-00 | Spring, Tension | 1 шт. | — | |
|
| 31 | 90506-29007-00 | Spring, Tension | 1 шт. | — | |
|
| 32 | 90185-10037-00 | Nut, Self-Locking | 2 шт. | — | |
|
| 33 | 90445-42002-00 | Hose | 1 шт. | — | |
|
| 34 | 90445-217G3-00 | Hose (L70) | 1 шт. | — | |
|
| 35 | 2RD-27311-00-00 | Stand, Side | 1 шт. | — | |
|
| 36 | 90109-10005-00 | Bolt | 1 шт. | — | |
|
| 37 | 90185-10037-00 | Nut, Self-Locking | 1 шт. | — | |
|
| 38 | 3VD-27315-00-00 | Link, Side Stand | 1 шт. | — | |
|
| 39 | 90506-26225-00 | Spring, Tension | 1 шт. | — | |
|
| 40 | 90506-18224-00 | Spring, Tension | 1 шт. | — | |
|
| 41 | 90445-266H4-00 | Hose (L55) | 1 шт. | — | |
|
| 42 | 3HT-27211-00-00 | Pedal, Brake | 1 шт. | — | |
|
| 43 | 3H0-27212-00-00 | Shaft, Brake Pedal | 1 шт. | — | |
|
| 44 | 90508-40381-00 | Spring, Torsion | 1 шт. | — | |
|
| 45 | 3H0-27231-00-00 | Rod, Brake | 1 шт. | — | |
|
| 46 | 90109-06468-00 | Bolt | 1 шт. | — | |
|
| 47 | 92907-06100-00 | Washer, Spring | 1 шт. | — | |
|
| 48 | 97007-06020-00 | Bolt | 1 шт. | — | |
|
| 49 | 95307-06700-00 | Nut | 1 шт. | — | |
|
| 50 | 90240-08067-00 | Pin, Clevis | 1 шт. | — | |
|
| 51 | 90201-08083-00 | Washer, Plate | 1 шт. | — | |
|
| 52 | 91401-20012-00 | Pin, Cotter | 1 шт. | — | |
|
| 53 | 90501-10245-00 | Spring, Compression | 1 шт. | — | |
|
| 54 | 90249-12008-00 | Pin | 1 шт. | — | |
|
| 55 | 90175-06013-00 | Nut, Wing | 1 шт. | — | |
|
