| 1 | 2SA-23102-00-00 | Front Fork Assy (L.H) | 1 шт. | — | |
|
| 2 | 2SA-F3126-00-00 | . .Tube, Outer (L.H) | 0 шт. | — | |
|
| 3 | BE8-F3145-00-00 | . . ..Oil Seal | 1 шт. | — | |
|
| 4 | 4RT-F3153-00-00 | . . ..Ring, Snap | 1 шт. | — | |
|
| 5 | 2SA-F3110-00-00 | . . Inner Tube Comp. 1 | 1 шт. | — | |
|
| 6 | 2SA-F3170-00-00 | . .Cylinder Comp., Front Fork | 1 шт. | — | |
|
| 7 | 1FP-F3157-00-00 | . .Ring, Piston | 1 шт. | — | |
|
| 8 | 49P-F3151-00-00 | . .Spring, Rebound | 1 шт. | — | |
|
| 9 | 2SA-F3479-00-00 | . .Gasket | 1 шт. | — | |
|
| 10 | 2SA-F3356-00-00 | . .Bolt 2 | 0 шт. | — | |
|
| 11 | BE8-F3144-00-00 | . .Seal, Dust | 1 шт. | — | |
|
| 12 | 2SA-23141-00-00 | . .Spring, Front Fork | 1 шт. | — | |
|
| 13 | 2SA-23427-00-00 | . .Washer | 1 шт. | — | |
|
| 14 | 2SA-23118-00-00 | . .Spacer | 1 шт. | — | |
|
| 15 | 2SA-F3147-00-00 | . .O-Ring | 1 шт. | — | |
|
| 16 | 2SA-23357-00-00 | . .Nut | 1 шт. | — | |
|
| 17 | 2SA-23103-00-00 | Front Fork Assy (R.H) | 1 шт. | — | |
|
| 18 | 2SA-F3136-00-00 | . .Tube, Outer 2 | 0 шт. | — | |
|
| 19 | BE8-F3145-00-00 | . . ..Oil Seal | 1 шт. | — | |
|
| 20 | 4RT-F3153-00-00 | . . ..Ring, Snap | 1 шт. | — | |
|
| 21 | 2SA-F3110-00-00 | . . Inner Tube Comp. 1 | 1 шт. | — | |
|
| 22 | 2SA-F3170-00-00 | . .Cylinder Comp., Front Fork | 1 шт. | — | |
|
| 23 | 1FP-F3157-00-00 | . .Ring, Piston | 1 шт. | — | |
|
| 24 | 49P-F3151-00-00 | . .Spring, Rebound | 1 шт. | — | |
|
| 25 | 2SA-F3479-00-00 | . .Gasket | 1 шт. | — | |
|
| 26 | 2SA-F3356-00-00 | . .Bolt 2 | 0 шт. | — | |
|
| 27 | BE8-F3144-00-00 | . .Seal, Dust | 1 шт. | — | |
|
| 28 | 2SA-23141-00-00 | . .Spring, Front Fork | 1 шт. | — | |
|
| 29 | 2SA-23427-00-00 | . .Washer | 1 шт. | — | |
|
| 30 | 2SA-23118-00-00 | . .Spacer | 1 шт. | — | |
|
| 31 | 2SA-F3147-00-00 | . .O-Ring | 1 шт. | — | |
|
| 32 | 2SA-23357-00-00 | . .Nut | 1 шт. | — | |
|
| 33 | 2SA-23340-00-00 | Under Bracket Comp | 1 шт. | — | |
|
| 34 | 3YJ-23414-00-00 | Race, Ball 4 | 1 шт. | — | |
|
| 35 | 95027-08030-00 | Bolt, Flange | 2 шт. | — | |
|
| 36 | 4X4-23435-00-00 | Crown, Handle | 1 шт. | — | |
|
| 37 | 90105-10006-00 | Bolt, Flange | 3 шт. | — | |
|
| 38 | 90209-10160-00 | Washer | 1 шт. | — | |
|
| 39 | 90201-105H3-00 | Washer, Plate | 2 шт. | — | |
|
| 40 | 2E9-23412-00-00 | Race, Ball 2 | 1 шт. | — | |
|
| 41 | 2E9-23413-01-00 | Race, Ball 3 | 1 шт. | — | |
|
| 42 | 3PT-23411-00-00 | Race, Ball 1 | 1 шт. | — | |
|
| 43 | 93505-32042-00 | Ball | 2 шт. | — | |
|
| 44 | 4X4-21543-00-00 | Plate 1 | 1 шт. | — | |
|
| 45 | 90159-06060-00 | Screw, With Washer | 2 шт. | — | |
|
