| 1 | 1TP-22110-00-00 | Rear Arm Comp | 1 шт. | — | |
|
| 2 | 1TP-22141-00-00 | Shaft, Pivot | 1 шт. | — | |
|
| 3 | 90387-16030-00 | Collar | 2 шт. | — | |
|
| 4 | 93108-44001-00 | Oil Seal | 2 шт. | — | |
|
| 5 | 95602-16100-00 | Nut, U | 1 шт. | — | |
|
| 6 | 93317-52897-00 | Bearing | 2 шт. | — | |
|
| 7 | 90387-16032-00 | Collar | 2 шт. | — | |
|
| 8 | 93109-28001-00 | Oil Seal | 2 шт. | — | |
|
| 9 | 1TP-2219X-00-00 | Cover | 2 шт. | — | |
|
| 10 | 1TP-22311-00-00 | Case, Chain | 1 шт. | — | |
|
| 11 | 90111-06127-00 | Bolt, Hex. Socket Button | 4 шт. | — | |
|
| 12 | 1TP-22312-00-00 | Case, Chain 2 | 1 шт. | — | |
|
| 13 | 90387-06048-00 | Collar | 2 шт. | — | |
|
| 14 | BL3-21668-A0-00 | Label, Tire | 1 шт. | — | |
|
| 15 | BL3-22210-00-00 | Shock Absorber Assy, Rear | 1 шт. | — | |
|
| 16 | BL3-22220-00-00 | Shock Absorber Assy, Rear | 1 шт. | — | |
|
| 17 | 90201-10074-00 | Washer, Plate | 2 шт. | — | |
|
| 18 | 90176-10073-00 | Nut, Crown | 2 шт. | — | |
|
| 19 | 90201-08119-00 | Washer, Plate | 2 шт. | — | |
|
| 20 | 90149-08054-00 | Screw | 2 шт. | — | |
|
