| 1 | 1D7-W2587-20-00 | Master Cylinder Sub Assy | 1 шт. | — | |
|
| 2 | 5PX-W0041-00-00 | . .Cylinder Kit, Master | 1 шт. | — | |
|
| 3 | 1D7-25852-20-00 | . .Cap, Reservoir | 1 шт. | — | |
|
| 4 | 1D7-2585B-00-00 | . .Plate, Diaphragm | 1 шт. | — | |
|
| 5 | 1D7-25854-01-00 | . .Diaphragm, Reservoir | 1 шт. | — | |
|
| 6 | 1D7-2589H-00-00 | . .Screw | 2 шт. | — | |
|
| 7 | 1D7-2589F-00-00 | . Bolt, Lever | 1 шт. | — | |
|
| 8 | 95604-06100-00 | . Nut, U | 1 шт. | — | |
|
| 9 | 4HM-83980-00-00 | . Front Stop Switch Assy | 1 шт. | — | |
|
| 10 | 98502-04012-00 | . Screw, Pan Head | 0 шт. | — | |
|
| 11 | 92907-04100-00 | . .Washer, Spring | 1 шт. | — | |
|
| 12 | 92907-04600-00 | . Washer | 1 шт. | — | |
|
| 13 | 1D7-26467-20-00 | Holder | 1 шт. | — | |
|
| 14 | 1D7-83922-10-00 | Lever 2 | 1 шт. | — | |
|
| 15 | 91312-06025-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 16 | 5C7-25872-00-00 | Hose, Brake 1 | 1 шт. | — | |
|
| 17 | 90401-10172-00 | Bolt, Union | 1 шт. | — | |
|
| 18 | 90430-10005-00 | Gasket | 2 шт. | — | |
|
| 19 | 90401-10172-00 | Bolt, Union | 2 шт. | — | |
|
| 20 | 90430-10005-00 | Gasket | 4 шт. | — | |
|
| 21 | 5C7-25886-00-00 | Holder, Brake Hose | 1 шт. | — | |
|
| 22 | 90105-06639-00 | Bolt, Flange | 1 шт. | — | |
|
| 23 | 5C7-25887-00-00 | Holder, Brake Hose | 1 шт. | — | |
|
| 24 | 95027-06020-00 | Bolt, Flange | 1 шт. | — | |
|
| 25 | 90105-06063-00 | Bolt, Flange | 1 шт. | — | |
|
| 26 | 5C7-25875-00-00 | Holder, Brake Hose 1 | 1 шт. | — | |
|
| 27 | 5C7-25192-00-00 | Stay | 1 шт. | — | |
|
| 28 | 95027-06010-00 | Bolt, Flange | 1 шт. | — | |
|
| 29 | 5C7-25876-00-00 | Holder, Brake Hose 2 | 1 шт. | — | |
|
| 30 | 5C7-2519F-00-00 | Stay 2 | 1 шт. | — | |
|
| 31 | 95027-06010-00 | Bolt, Flange | 1 шт. | — | |
|
| 32 | 1D7-W2645-20-00 | Master Cylinder Sub Assy | 1 шт. | — | |
|
| 33 | 1D7-W0099-00-00 | . .Cylinder Kit, Master (Clutch | 1 шт. | — | |
|
| 34 | 1D7-25852-70-00 | . .Cap, Reservoir | 1 шт. | — | |
|
| 35 | 1D7-2585B-10-00 | . .Plate, Diaphragm | 1 шт. | — | |
|
| 36 | 1D7-26464-00-00 | . .Rod, Push | 1 шт. | — | |
|
| 37 | 3GM-26455-00-00 | . .Bush | 1 шт. | — | |
|
| 38 | 1D7-25854-11-00 | . .Diaphragm, Reservoir | 1 шт. | — | |
|
| 39 | 1D7-2589H-00-00 | . .Screw | 2 шт. | — | |
|
| 40 | 1D7-2589F-00-00 | Bolt, Lever | 1 шт. | — | |
|
| 41 | 95604-06100-00 | Nut, U | 1 шт. | — | |
|
| 42 | 3YX-82917-01-00 | Switch | 1 шт. | — | |
|
| 43 | 90151-03002-00 | Screw, Countersunk | 1 шт. | — | |
|
| 44 | 1D7-83912-10-00 | Lever 1 | 1 шт. | — | |
|
| 45 | 1D7-26467-70-00 | Holder | 1 шт. | — | |
|
| 46 | 91312-06025-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 47 | 90105-06791-00 | Bolt, Flange | 1 шт. | — | |
|
| 48 | 5C7-26472-00-00 | Hose, Clutch 1 | 1 шт. | — | |
|
| 49 | 5C7-26473-00-00 | Hose, Clutch 2 | 1 шт. | — | |
|
| 50 | 90401-10172-00 | Bolt, Union | 2 шт. | — | |
|
| 51 | 90430-10005-00 | Gasket | 4 шт. | — | |
|
| 52 | 1D7-26477-00-00 | Cover | 1 шт. | — | |
|
| 53 | 1D7-26475-00-00 | Holder | 1 шт. | — | |
|
| 54 | 91312-06014-00 | Bolt, Hexagon Socket Head | 1 шт. | — | |
|
| 55 | 91312-06014-00 | Bolt, Hexagon Socket Head | 1 шт. | — | |
|
| 56 | 5C7-26481-00-00 | Holder, 2 | 1 шт. | — | |
|
| 57 | 90111-06102-00 | Bolt, Hex. Socket Button | 1 шт. | — | |
|
| 58 | 5C7-26482-00-00 | Holder, 3 | 1 шт. | — | |
|
| 59 | 90111-06102-00 | Bolt, Hex. Socket Button | 1 шт. | — | |
|
