| 1 | 5C7-22110-01-00 | Rear Arm Comp | 1 шт. | — | |
|
| 2 | 93317-42599-00 | Bearing | 2 шт. | — | |
|
| 3 | 1D7-22184-00-00 | Bush | 1 шт. | — | |
|
| 4 | 1D7-22126-00-00 | Collar, Distance | 2 шт. | — | |
|
| 5 | 93109-33049-00 | Oil Seal | 2 шт. | — | |
|
| 6 | 5PX-22141-10-00 | Shaft, Pivot | 1 шт. | — | |
|
| 7 | 90185-18009-00 | Nut, Self-Locking | 1 шт. | — | |
|
| 8 | 90201-18020-00 | Washer, Plate | 1 шт. | — | |
|
| 9 | 1D7-2217A-01-00 | Arm, Relay | 1 шт. | — | |
|
| 10 | 5C7-2217M-00-00 | Arm 1 | 2 шт. | — | |
|
| 11 | 93317-31798-00 | Bearing | 2 шт. | — | |
|
| 12 | 1D7-2248B-00-00 | Collar, Rod 1 | 1 шт. | — | |
|
| 13 | 90387-12032-00 | Collar | 2 шт. | — | |
|
| 14 | 90101-12018-00 | Bolt | 1 шт. | — | |
|
| 15 | 95612-12100-00 | Nut, U | 1 шт. | — | |
|
| 16 | 90201-12045-00 | Washer, Plate | 1 шт. | — | |
|
| 17 | 93315-32053-00 | Bearing | 2 шт. | — | |
|
| 18 | 90387-12035-00 | Collar | 1 шт. | — | |
|
| 19 | 90101-12027-00 | Bolt | 1 шт. | — | |
|
| 20 | 95612-12100-00 | Nut, U | 1 шт. | — | |
|
| 21 | 90201-12045-00 | Washer, Plate | 1 шт. | — | |
|
| 22 | 90201-13013-00 | Washer, Plate | 2 шт. | — | |
|
| 23 | 93315-31759-00 | Bearing | 1 шт. | — | |
|
| 24 | 93109-17071-00 | .Oil Seal | 4 шт. | — | |
|
| 25 | 93109-20001-00 | Oil Seal | 2 шт. | — | |
|
| 26 | 90384-18157-00 | Bush, Bimetal Formed | 4 шт. | — | |
|
| 27 | 93210-18397-00 | O-Ring | 4 шт. | — | |
|
| 28 | 5C7-22310-00-00 | Chain Case Assy | 1 шт. | — | |
|
| 29 | 90149-06298-00 | Screw | 2 шт. | — | |
|
| 30 | 5C7-22312-00-00 | Case, Chain 2 | 1 шт. | — | |
|
| 31 | 90149-06298-00 | Screw | 2 шт. | — | |
|
| 32 | 90269-08001-00 | Rivet | 1 шт. | — | |
|
| 33 | 90387-065T2-00 | .Collar | 2 шт. | — | |
|
| 34 | 1D7-22358-00-00 | Seal 1 | 1 шт. | — | |
|
| 35 | 1D7-22128-00-00 | Cover, Thrust 1 | 1 шт. | — | |
|
| 36 | 5C7-22210-00-00 | Shock Absorber Assy, Rear | 1 шт. | — | |
|
| 37 | 4AA-22259-80-00 | . .Label, Warning | 1 шт. | — | |
|
| 38 | 90387-1214E-00 | Collar | 1 шт. | — | |
|
| 39 | 90101-12017-00 | Bolt | 1 шт. | — | |
|
| 40 | 95602-12200-00 | Nut, Self-Locking | 1 шт. | — | |
|
| 41 | 90201-12045-00 | Washer, Plate | 1 шт. | — | |
|
| 42 | 90387-127W0-00 | Collar | 1 шт. | — | |
|
| 43 | 90101-10659-00 | Bolt | 1 шт. | — | |
|
| 44 | 95612-10100-00 | Nut, U | 1 шт. | — | |
|
| 45 | 90201-10035-00 | Washer, Plate | 1 шт. | — | |
|
