| 1 | 5C7-27211-00-00 | Pedal, Brake | 1 шт. | — | |
|
| 2 | 5VN-18113-00-00 | Cover, Shift Pedal | 1 шт. | — | |
|
| 3 | 5C7-27813-01-00 | Pin, Pedal Crank | 1 шт. | — | |
|
| 4 | 95604-06100-00 | Nut, U | 1 шт. | — | |
|
| 5 | 5C7-27434-00-00 | Bolt | 1 шт. | — | |
|
| 6 | 90201-18022-00 | Washer, Plate | 1 шт. | — | |
|
| 7 | 90201-08061-00 | Washer, Plate | 1 шт. | — | |
|
| 8 | 5C7-27316-00-00 | Spring, Side Stand | 1 шт. | — | |
|
| 9 | 91701-06018-00 | Pin | 1 шт. | — | |
|
| 10 | 91402-16012-00 | Pin, Cotter | 1 шт. | — | |
|
| 11 | 92902-06200-00 | Washer | 1 шт. | — | |
|
| 12 | 5C7-27222-00-00 | Joint | 1 шт. | — | |
|
| 13 | 95307-08700-00 | .Nut | 1 шт. | — | |
|
| 14 | 1D7-25867-00-00 | Bracket, Master Cylinder | 1 шт. | — | |
|
| 15 | 92014-08035-00 | Bolt, Button Head | 2 шт. | — | |
|
| 16 | 5PX-27491-00-00 | Protector | 1 шт. | — | |
|
| 17 | 92014-08014-00 | Bolt, Button Head | 2 шт. | — | |
|
| 18 | 1D7-2583V-00-00 | Rear Master Cylinder Assy | 1 шт. | — | |
|
| 19 | 1FK-W0042-50-00 | . .Cylinder Kit, Master | 1 шт. | — | |
|
| 20 | 2VN-25866-00-00 | . .Circlip | 1 шт. | — | |
|
| 21 | 93210-15620-00 | . .O-Ring | 1 шт. | — | |
|
| 22 | 2VN-2582A-50-00 | . .Joint | 1 шт. | — | |
|
| 23 | 92014-08035-00 | Bolt, Button Head | 2 шт. | — | |
|
| 24 | 1D7-25895-00-00 | Hose, Reservoir | 1 шт. | — | |
|
| 25 | 90467-12191-00 | Clip | 2 шт. | — | |
|
| 26 | 5YU-25894-00-00 | Tank, Reservoir | 1 шт. | — | |
|
| 27 | 55U-25854-00-00 | .Diaphragm, Reservoir | 1 шт. | — | |
|
| 28 | 3GM-2585B-20-00 | .Plate, Diaphragm | 1 шт. | — | |
|
| 29 | 5YU-25852-00-00 | .Cap, Reservoir | 1 шт. | — | |
|
| 30 | 98706-04040-00 | Screw, Flat Head | 2 шт. | — | |
|
| 31 | 92012-06014-00 | Bolt, Button Head | 1 шт. | — | |
|
| 32 | 90464-14005-00 | Clamp | 1 шт. | — | |
|
| 33 | 90464-15192-00 | Clamp | 1 шт. | — | |
|
| 34 | 1D7-21374-00-00 | Holder, Fuel Pipe | 1 шт. | — | |
|
| 35 | 90464-14006-00 | Clamp | 2 шт. | — | |
|
| 36 | 1D7-25881-00-00 | Protector, Brake Hose | 1 шт. | — | |
|
| 37 | 12R-82591-00-00 | Band | 2 шт. | — | |
|
| 38 | 5C7-2581J-00-00 | Hose, Brake 4 | 1 шт. | — | |
|
| 39 | 1D7-2588F-00-00 | Holder, Brake Hose 5 | 1 шт. | — | |
|
| 40 | 95022-06012-00 | .Bolt, Flange | 1 шт. | — | |
|
| 41 | 5C7-2587A-00-00 | Holder, Brake Hose | 1 шт. | — | |
|
| 42 | 90105-06078-00 | Bolt, Flange | 2 шт. | — | |
|
| 43 | 5GJ-25886-10-00 | Holder, Brake Hose | 1 шт. | — | |
|
| 44 | 95022-06010-00 | Bolt, Flange | 1 шт. | — | |
|
| 45 | 90401-10172-00 | Bolt, Union | 2 шт. | — | |
|
| 46 | 90430-10005-00 | Gasket | 4 шт. | — | |
|
