| 1 | 90201-12790-00 | Washer, Plate | 1 шт. | — | |
|
| 2 | 5YP-85790-00-00 | Thermosensor Assy | 1 шт. | — | |
|
| 3 | 20S-81670-00-00 | Pick-Up Assy | 1 шт. | — | |
|
| 4 | 90110-06161-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 5 | 20S-82566-60-00 | Switch, Side Stand | 1 шт. | — | |
|
| 6 | 92012-05025-00 | Bolt, Button Head | 2 шт. | — | |
|
| 7 | 95602-05200-00 | Nut, Self-Locking | 2 шт. | — | |
|
| 8 | 20S-82530-01-00 | Stop Switch Assy | 1 шт. | — | |
|
| 9 | 20S-82310-00-00 | Ignition Coil Assy | 1 шт. | — | |
|
| 10 | 20S-82370-01-00 | Plug Cap Assy | 2 шт. | — | |
|
| 11 | 20S-82320-00-00 | Ignition Coil Assy | 1 шт. | — | |
|
| 12 | 20S-82370-01-00 | Plug Cap Assy | 2 шт. | — | |
|
| 13 | 97702-60525-00 | Screw, Tapping | 2 шт. | — | |
|
| 14 | 90338-08226-00 | Plug | 2 шт. | — | |
|
| 15 | 3GB-82540-01-00 | Neutral Switch Assy | 1 шт. | — | |
|
| 16 | 90430-10148-00 | Gasket | 1 шт. | — | |
|
| 17 | 5VX-85720-01-00 | Oil Level Gauge Assy | 1 шт. | — | |
|
| 18 | 5VY-8A8E0-00-00 | . .O-Ring | 1 шт. | — | |
|
| 19 | 90105-06187-00 | Bolt, Flange | 2 шт. | — | |
|
| 20 | 4WM-83755-02-00 | Sensor, Speed | 1 шт. | — | |
|
| 21 | 4D9-81168-00-00 | . .O-Ring | 1 шт. | — | |
|
| 22 | 91312-06016-00 | Bolt, Hexagon Socket Head | 1 шт. | — | |
|
| 23 | 20S-81673-00-00 | Rotor | 1 шт. | — | |
|
| 24 | 90105-08113-00 | Bolt, Flange | 1 шт. | — | |
|
| 25 | 90201-08054-00 | Washer, Plate | 1 шт. | — | |
|
| 26 | 90464-15065-00 | Clamp | 1 шт. | — | |
|
| 27 | 11H-85110-01-00 | Reflector Assy | 2 шт. | — | |
|
| 28 | 95602-05200-00 | Nut, Self-Locking | 2 шт. | — | |
|
| 29 | 36P-85112-00-00 | Bracket, Reflector 1 | 2 шт. | — | |
|
